Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-5
Type
Device
Item Range Function
Frequency
measurement card
interruption
I180, 1 point
K Decimal form
K-32,768 ~ K32,767 (16-bit operation)
K-2,147,483,648 ~ K2,147,483,647 (32-bit operation)
Constant
H Hexadecimal form
H0000 ~ HFFFF (16-bit operation)
H00000000 ~ HFFFFFFFF (32-bit operation)
*1. Non-latched area cannot be modified.
*2. The preset non-latched area can be modified into latched area by setting up parameters.
*3. The preset latched area can be modified into non-latched area by setting up parameters.
*4. The fixed latched area cannot be modified
Latched settings for all devices in EH/EH2/SV series MPU:
*1: K-1 refers to the default setting is non-latched.
 Power On/Off or the MPU switches between RUN/STOP:
Memory of ES/EX/SS V5.5 (and above)
Memory type
Power
Off→On
STOP→RUN RUN→STOP
Clear all non-latched
areas (M1031)
Clear all latched
areas (M1032)
Default
setting
Clear when M1033 = Off
Non-latched Clear
Remain unchanged when M1033 = On
Clear Unchanged 0
Latched Unchanged Unchanged Clear Unchanged
Special M,
Special D,
index register
Initial Unchanged Unchanged Initial setting
Memory of SA/SX/SC/EH/EH2/SV series MPU:
General purpose Latched Special auxiliary relay Latched
M0 ~ M499 M500 ~ M999 M1000 ~ M1999 M2000 ~ M4095
M
(Auxiliary relay)
Start: D1200 (K500)
End: D1201 (K999)
Some are latched and
cannot be modified.
Start: D1202 (K2,000)
End: D1203 (K4,095)
100 ms 10 ms 10 ms 1 ms 100 ms
T0 ~ T199 T200 ~ T239 T240 ~ T245 T246 ~ T249 T250 ~ T255
Default: non-latched Default: non-latched
T
(Timer)
Start: D1204 (K-1)*1
End: D1205 (K-1)*1
Start: D1206 (K-1)*1
End: D1207 (K-1)*1
Accumulative type
It is fixed to be latched.
16-bit counting up 32-bit counting up/down 32-bit high-speed counting up/down
C0 ~ C99 C100 ~ C199 C200 ~ C219 C220 ~ C234 C235 ~ C245 C246 ~ C255
Default:
non-latched
Default: latched
Default:
non-latched
Default: latched Default: latched
C
(Counter)
Start: D1208 (K100)
End: D1209 (K199)
Start: D1210 (K220)
End: D1211 (K234)
Start: D1212 (K235)
End: D1213 (K255)
Initial Zero return
General
purpose
Latched Step alarm
S0 ~ S9 S10 ~ S19 S20 ~ S499 S500 ~ S899 S900 ~ S1023
Non-latched (default) Latched (default)
S
(Step relay)
Start: D1214 (K500)
End: D1215 (K899)
It is fixed to be latched.
General purpose Latched Special register Latched
D0 ~ D199 D200 ~ D999 D1000 ~ D1999 D2000 ~ D9999
Default: non-latched Default: latched Default: latched
D
(Register)
Start: D1216 (K200)
End: D1217 (K999)
Some is latched and
cannot be modified.
Start: D1218 (K2,000)
End: D1219 (K9,999)
K0 ~ K9,999
File register
It is fixed to be latched.
