Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-126
Error
code
Cause of error
Error
code
Cause of error
0D0B Improper use of operands in IST instruction
C40F
PLC program and data in parameters have not
been initialized
0E01
Use of device C exceeds the range
C41B
Invalid RUN/STOP instruction to extension
module
0E04
Use of register C exceeds the range
C41C
Points of extension module exceed the range
0E05
Improper use of operand CXXX of DCNT
instsruction
C41D
Number of extension modules exceeds the
range
0E18
BCD conversion error
C41E
Incorrect hardware setting for extension module
0E19
Division error (divisor = 0)
C41F
Failing to write data into memory
0E1A
Use of device exceeds the range (including E,
F index register modification)
C420
Read/write function card error
0E1B
The index of the radical is a negative value
C430
Initializing parallel interface error
0E1C
Communication error of FROM/TO instruction
C440
Hardware error in high-speed counter
0F04
Use of register D exceeds the range
C441
Hardware error in high-speed comparator
0F05
Improper use of operand DXXX of DCNT
instruction
C442
Hardware error in MCU pulse output
0F06
Improper use of operands of SFTR instruction
C443
No response from extension unit
0F07
Improper use of operands of SFTL instruction
C4EE
No END instruction in the program
0F08
Improper use of operands of REF instruction
C4FF
Invalid instruction (no such instruction existing)
0F09
Improper use of operands of WSFR, WSFL
instructions
