Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-7
External output: Y0 ~ Y7, Y10 ~ Y17…(device No.)
3. Decimal value (DEC)
Occassions of using decimal values in DVP-PLC:
 Set value in timer T and counter C, e.g. TMR C0 K50 (constant K)
 No. of device S, M, T, C, D, E, F, P, I, e.g. M10, T30. (device No.)
 Operands in application instructions, e.g. MOV K123 D0 (constant K)
4. Binary code decimal (BCD)
A decimal datum is presented by a nibble or 4 bits. Therefore, a continuous 16 bits can be presented as a 4-digit
decimal value. BCD is mainly used on reading the input value from the DIP switch or the data output to a 7-section
display.
5. Hexadecimal value (HEX)
Occassion of using hexadecimal values:
 Operands in application instructions, e.g. MOV H1A2B D0 (constant H)
Constant K:
“K” is normally placed before a decimal value in the PLC. For example, K100 refers to a decimal value, 100.
Exception:
K and bit devices X, Y, M and S can combine into data in bit, byte, word or double word, e.g. K2Y10, K4M100.
Here K1 refers to a 4-bit data and K2 ~ K4 refer to 8-bit, 12-bit and 16-bit data.
Constant H:
“H” is normally placed before a hexadecimal value in the PLC. For example, H100 refers to a hexadecimal value,
100.
Reference table:
Binary
(BIN)
Octal
(OCT)
Decimal
(DEC)
Binary Code Decimal
(BCD)
Hexadecimal
(HEX)
For PLC internal operation
No. of device
X, Y
Constant K,
No. of device M, S, T, C,
D, E, F, P, I
For DIP switch and 7-section
display
Constant H
0000 0000 0 0 0 0 0 0 0 0 0 0 0
0000 0001 1 1 0 0 0 0 0 0 0 1 1
0000 0010 2 2 0 0 0 0 0 0 1 0 2
0000 0011 3 3 0 0 0 0 0 0 1 1 3
0000 0100 4 4 0 0 0 0 0 1 0 0 4
0000 0101 5 5 0 0 0 0 0 1 0 1 5
0000 0110 6 6 0 0 0 0 0 11 0 6
0000 0111 7 7 0 0 0 0 0 1 1 1 7
0000 1000 10 8 0 0 0 0 1 0 0 0 8
0000 1001 11 9 0 0 0 0 1 0 0 1 9
0000 1010 12 10 0 0 0 1 0 0 0 0 A
0000 1011 13 11 0 0 0 1 0 0 0 1 B
0000 1100 14 12 0 0 0 1 0 0 1 0 C
0000 1101 15 13 0 0 0 1 0 0 11 D
0000 1110 16 14 0 0 0 1 0 1 0 0 E
0000 1111 17 15 0 0 0 1 0 1 0 1 F
0001 0000 20 16 0 0 0 1 0 1 1 0 10

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
