Delta DVP-PLC User Manual

7 Application Instructions API 50-99
DVP-PLC APPLICATION MANUAL
7-97
6. When n = 1 ~ 16:
n
D
K1 K2 K3 K4 K5 K6 K7 K8
D20 “3” “2” “1” “0” “7” “6” “5” “4”
D21 “3” “2” “1” “0” “7” “6” “5”
D22 “3” “2” “1” “0” “7” “6”
D23 “3” “2” “1” “0” “7”
D24 “3” “2” “1” “0”
D25 “3” “2” “1”
D26 “3” “2”
D27 “3”
D28
D29
D30
D31
D32
D33
D34
D35
no
change
n
D
K9 K10 K11 K12 K13 K14 K15 K16
D20 “B” “A” “9” “8” “F” “E” “D” “C”
D21 “4” “B” “A” “9” “8” “F” “E” “D”
D22 “5” “4” “B” “A” “9” “8” “F” “E”
D23 “6” “5” “4” “B” “A” “9” “8” “F”
D24 “7” “6” “5” “4” “B” “A” “9” “8”
D25 “0” “7” “6” “5” “4” “B” “A” “9”
D26 “1” “0” “7” “6” “5” “4” “B” “A”
D27 “2” “1” “0” “7” “6” “5” “4” “B”
D28 “3” “2” “1” “0” “7” “6” “5” “4”
D29 “3” “2” “1” “0” “7” “6” “5”
D30 “3” “2” “1” “0” “7” “6”
D31 “3” “2” “1” “0” “7”
D32 “3” “2” “1” “0”
D33 “3” “2” “1”
D34 “3” “2”
D35
no
change
“3”

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
