Delta DVP-PLC User Manual

7 Application Instructions API 50-99
DVP-PLC APPLICATION MANUAL
7-100
3. When n = 2, the bit structure will be as:
0100
0010
00 0 11 1
D20
D21
D10
11 0
010
00
00 00 0 0 0
0
11
43H
C
44H
D
CD
4. When n = 1 ~ 16:
D
n
D13 D12 D11 D10
1 ***C H
2 **CD H
3 *CDE H
4 CDEF H
5 ***C H DEF8 H
6 **CD H EF89 H
7 *CDE H F89A H
8 CDEF H 89AB H
9 ***C H DEF8 H 9AB4 H
10 **CD H EF89 H AB45 H
11 *CDE H F89A H B456 H
12
The used
registers
which are not
specified are
all 0
CDEF H 89AB H 4567 H
13 ***C H DEF8 H 9AB4 H 5670 H
14 **CD H EF89 H AB45 H 6701 H
15 *CDE H F89A H B456 H 7012 H
16 CDEF H 89AB H 4567 H 0123 H
