Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-24
Flag Function
M1290 High speed counter I020 interruption forbidden
M1291 High speed counter I030 interruption forbidden
M1292 High speed counter I040 interruption forbidden
M1293 High speed counter I050 interruption forbidden
M1294 High speed counter I060 interruption forbidden
M1312 C235 Start input point control
M1313 C236 Start input point control
M1314 C237 Start input point control
M1315 C238 Start input point control
M1316 C239 Start input point control
M1317 C240 Start input point control
M1320 C235 Reset input point control
M1321 C236 Reset input point control
M1322 C237 Reset input point control
M1323 C238 Reset input point control
M1324 C239 Reset input point control
M1325 C240 Reset input point control
M1328 Enable Start/Reset of C235
M1329 Enable Start/Reset of C236
M1330 Enable Start/Reset of C237
M1331 Enable Start/Reset of C238
M1332 Enable Start/Reset of C239
M1333 Enable Start/Reset of C240
D1022
Multiplied frequency of A-B phase counters for ES/EX/SS and SA/SX/SC
series MPU
D1150 Table counting register for DHSZ multiple set values comparison mode
D1151 Register for DHSZ instruction frequency control mode (counting by table)
D1152 (low word)
D1153 (high word)
In frequency control mode, DHSZ reads the upper and lower limits in the table
counting register D1153 and D1152.
D1166
Switching between rising/falling edge counting modes of X10 (for SC_V1.4
series MPU only)
D1167
Switching between rising/falling edge counting modes of X11 (for SC_V1.4
series MPU only)
D1225 The counting mode of the 1
st
group counters (C241, C246, C251)
D1226 The counting mode of the 2
nd
group counters (C242, C247, C252)
D1227 The counting mode of the 3
rd
group counters (C243, C248, C253)
D1228 The counting mode of the 4
th
group counters (C244, C249, C254)

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
