2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-42
Special
M
Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STO
P
Attribute Latched Default
M1234 Counting mode of C234 (On: counting down)
╳
○ ○
Off - - R/W NO Off
M1235 Counting mode of C235 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1236 Counting mode of C236 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1237 Counting mode of C237 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1238 Counting mode of C238 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1239 Counting mode of C239 (On: counting down)
╳
○ ○
Off - - R/W NO Off
M1240 Counting mode of C240 (On: counting down)
╳
○ ○
Off - - R/W NO Off
M1241 Counting mode of C241 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1242 Counting mode of C242 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1243 Counting mode of C243 (On: counting down)
╳
○ ○
Off - - R/W NO Off
M1244 Counting mode of C244 (On: counting down)
○ ○ ○
Off - - R/W NO Off
M1245 Counting mode of C245 (On: counting down)
╳
○
╳
Off - - R/W NO Off
M1246 C246 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1247 C247 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1248 C248 counter monitoring (On: counting down)
╳ ╳
○
Off - - R NO Off
M1249 C249 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1250 C250 counter monitoring (On: counting down)
╳
○
╳
Off - - R NO Off
M1251 C251 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1252 C252 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1253 C253 counter monitoring (On: counting down)
╳ ╳
○
Off - - R NO Off
M1254 C254 counter monitoring (On: counting down)
○ ○ ○
Off - - R NO Off
M1255 C255 counter monitoring (On: counting down)
╳
○
╳
Off - - R NO Off
M1258 Y0 pulse output signal reversing for PWM instruction
╳ ╳
○
Off - - R/W NO Off
M1259 Y2 pulse output signal reversing for PWM instruction
╳ ╳
○
Off - - R/W NO Off
M1260
X5 as the reset input signal for all high-speed
counters
╳
○
╳
Off - - R/W NO Off
M1261
High-speed comparator comparison flag for DHSCR
instruction
╳ ╳
○
Off - - R/W NO Off
M1264 Enabling reset function of HHSC0
╳ ╳
○
Off - - R/W NO Off
M1265 Enabling start function of HHSC0
╳ ╳
○
Off - - R/W NO Off
M1266 Enabling reset function of HHSC1
╳ ╳
○
Off - - R/W NO Off
M1267 Enabling start function of HHSC1
╳ ╳
○
Off - - R/W NO Off
M1268 Enabling reset function of HHSC2
╳ ╳
○
Off - - R/W NO Off
M1269 Enabling start function of HHSC2
╳ ╳
○
Off - - R/W NO Off
