Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-51
Special
M
Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STO
P
Attribute Latched Default
M1514* Indicating writing to Salve ID#27 is completed
╳ ╳
○
Off - - R NO Off
M1515* Indicating writing to Salve ID#28 is completed
╳ ╳
○
Off - - R NO Off
M1516* Indicating writing to Salve ID#29 is completed
╳ ╳
○
Off - - R NO Off
M1517* Indicating writing to Salve ID#30 is completed
╳ ╳
○
Off - - R NO Off
M1518* Indicating writing to Salve ID#31 is completed
╳ ╳
○
Off - - R NO Off
M1519* Indicating writing to Salve ID#32 is completed
╳ ╳
○
Off - - R NO Off
M1520
EH2/SV: stopping the 3
rd
group pulse output CH2
(Y4, Y5) (Not available in EH)
╳ ╳
○
Off - - R/W NO
Off
M1521
EH2/SV: stopping the 4
th
group pulse output CH3
(Y6, Y7) (Not available in EH)
╳ ╳
○
Off - - R/W NO
Off
M1522
EH2/SV: sending out the 3
rd
group pulse output CH2
(Y4, Y5) (Not available in EH)
╳ ╳
○
Off - Off R NO
Off
M1523
EH2/SV: sending out the 4
th
group pulse output CH3
(Y6, Y7) (Not available in EH)
╳ ╳
○
Off - Off R NO
Off
M1524
EH2/SV: reset after the 3
rd
group pulse output CH2
(Y4, Y5) is completed for PLSY instruction (Not
available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1525
EH2/SV: reset after the 4
th
group pulse output CH3
(Y6, Y7) is completed for PLSY instruction (Not
available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1526
EH2/SV: reversing Y4 pulse output signal for PWM
instruction (Not available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1527
EH2/SV: reversing Y6 pulse output signal for PWM
instruction (Not available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1530
EH2/SV: switching time base unit of Y4 output for
PWM instruction
On: 100us; Off: 1ms (Not available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1531
EH2/SV: switching time base unit of Y6 output for
PWM instruction
On: 100us; Off: 1ms (Not available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1532
EH2/SV: reverse operation of the 3
rd
group pulse
CH2 (Y4, Y5) for PLSV/DPLSV/DRVI/DDRVI/DRVA
/DDRVA instruction (Not available in EH)
╳ ╳
○
Off - - R/W
NO Off
M1533
EH2/SV: reverse operation of the 4
th
group pulse
CH3 (Y6, Y7) for PLSV/DPLSV/DRVI/DDRVI/DRVA
/DDRVA instruction
╳ ╳
○
Off - - R/W
NO Off
M1534
EH2/SV: CH0 being able to designate deceleration
time. Has to be used with D1348.
╳ ╳
○
Off - - R/W
NO
Off
M1535
EH2/SV: CH1 being able to designate deceleration
time. Has to be used with D1349.
╳ ╳
○
Off - - R/W
NO
Off
