Delta DVP-PM Series User Manual

4 Basic Instructions
DVP-PM Application Manual
4-1
4.1 Basic Instructions
 General Instructions
Instruction Function Operands
Execution speed
(us)
Step
Page
number
LD
Load NO contact
X, Y, M, S, T, C 3.3 3 4-3
LDI
Load NC contact
X, Y, M, S, T, C 3.3 3 4-3
AND
Connect NO contact in series
X, Y, M, S, T, C 3.3 3 4-3
ANI
Connect NC contact in series
X, Y, M, S, T, C 3.3 3 4-4
OR
Connect NO contact in parallel
X, Y, M, S, T, C 3.3 3 4-4
ORI
Connect NC contact in parallel
X, Y, M, S, T, C 3.3 3 4-4
ANB
Connect a block in series
N/A 2.3 3 4-5
ORB
Connect a block in parallel
N/A 2.3 3 4-5
 Output Instructions
Instruction Function Operands
Execution speed
(us)
Step
Page
number
OUT
Output coil
Y, M, S 7.3 3 4-6
SET
Latches the ON status
Y, M, S 5.6 3 4-6
RST
Resets contacts, registers or coils
Y, M, S, T, C, D, V, Z 6.9 3 4-7
 Timers, Counters
API Instruction Function Operands
Execution speed
(us)
Step
Page
number
96 TMR 16-bit timer T-K or T-D 19 5 4-7
97 CNT 16-bit counter C-K or C-D (16 bits) 16 5 4-8
97 DCNT 32-bit counter C-K or C-D (32 bits) 16.5 6 4-8
 Rising / Falling-Edge Triggers
API Instruction Function Operands
Execution speed
(us)
Step
Page
number
90 LDP Load Rising edge trigger X, Y, M, S, T, C 12.3 3 4-9
91 LDF Load Falling edge trigger X, Y, M, S, T, C 12.3 3 4-9
92 ANDP
Connect Rising edge in
series
X, Y, M, S, T, C 12.3 3 4-9
93 ANDF
Connect Falling edge in
series
X, Y, M, S, T, C 12.3 3 4-10
94 ORP
Connect Rising edge in
parallel
X, Y, M, S, T, C 12.6 3 4-10
95 ORF
Connect Falling edge in
parallel
X, Y, M, S, T, C 12.6 3 4-11
