5 Categories and Use of Basic Application Instructions
DVP-PM Operation Instruction
5-2
Mnemonic STEPS
Category
API
16-bit 32-bit
Pulse
Function 20PM 10PM
16-bit 32-bit
Page
43
SUM DSUM

Sum of Active bits
9
9
5 9 5-63
44
BON DBON

Check specified bit status
9
9
7 13 5-64
45
MEAN DMEAN

Mean
9
9
7 13 5-65
46
ANS - - Timed Annunciator Set
9
9
7 - 5-66
47
ANR -

Annunciator Reset
9
9
1 - 5-67
48
SQR DSQR

Square Root
9
9
5 9 5-69
49
- DFLT
9
Floating Point
9
9
- 6 5-70
High Speed
Processing
50
REF -

Refresh
9
9
5 - 5-72
61
SER DSER

Search a data stack
9
9
9 17 5-74
66
ALT -

Alternate state
9
9
3 - 5-75
67
RAMP DRAMP - Ramp variable value
9
9
9 17 5-76
Handy
Instructions
69
SORT DSORT - Data sort
9
9
11 21 5-78
78
FROM DFROM
9
Read CR Data from
Special Modules
9
9
9 12 5-80
79
TO DTO
9
Write CR Data into Special
Modules
9
9
9 13 5-81
I/O
87
ABS DABS

Absolute value
9
9
3 5 5-84
89
PLS - - Rising-edge Output
9
9
3 - 4-11
90
LDP - -
Rising-edge Detection
Operation
9
9
3 - 4-9
91
LDF - -
Falling-edge Detection
Operation
9
9
3 - 4-9
92
ANDP - -
Rising-edge Series
Connection
9
9
3 - 4-9
93
ANDF - -
Falling-edge Series
Connection
9
9
3 - 4-10
94
ORP - -
Rising-edge Parallel
Connection
9
9
3 - 4-10
95
ORF - -
Falling-edge Parallel
Connection
9
9
3 - 4-11
96
TMR - - 16-bit Timer
9
9
5 - 4-7
97
CNT DCNT - 16-bit/32-bit Counter
9
9
5 6 4-8
Basic
Instructions
99
PLF - - Falling-edge Output
9
9
3 - 4-12
100
MODRD - - Read Modbus Data
9
9
7 - 5-85
Communi-
cations
101
MODW
R
- - Write Modbus Data
9
9
7 - 5-89
110
- DECMP
9
Floating Point Compare
9
9
7 9 5-94
111
-
DEZCP
9
Floating Point Zone
Compare
9
9
9 12 5-95
112
DMOVR

Move floating point data
9
9
9 5-96
116
- DRAD 9
Degree → Radian
9
9 - 6 5-97
117
- DDEG 9
Radian → Degree
9
9 - 6 5-98
120
- DEADD
9
Floating Point Addition
9
9
7 9 5-99
121
- DESUB
9
Floating Point Subtraction
9
9
7 9 5-100
Floating Point
Operation
122
-
DEMUL
9
Floating Point
Multiplication
9
9
7 9 5-101
