5 Categories and Use of Basic Application Instructions
DVP-PM Application Manual 5-13
Mnemonic STEPS
API
16-bit 32-bit
P
Instruction
Function
16-bit 32-bit
Page
244
OR<> DOR<> - S1 ≠S2 5 7 5-127
245
OR<= DOR<= - S1 S2≦ 5 7 5-127
246
OR>= DOR>= - S1 S2≧ 5 7 5-127
89
PLS - - Rising-Edge Output 3 - 4-11
99
PLF - - Falling-Edge Output 3 - 4-12
P
128
- DPOW
9
Floating Point Power Operation - 9 5-105
08
RPT - -
Start of a Nested RPT-RPE loop (ONly I
level available)
3 - 5-19
09
RPE - - End of a Nested RPT-RPE loop 1 - 5-19
30
ROR DROR
9
Rotate right 5 9 5-46
31
ROL DROL
9
Rotate left 5 9 5-47
32
RCR DRCR
9
Rotate right with carry 5 9 5-48
33
RCL DRCL
9
Rotate left with carry 5 9 5-49
50
REF -

Refresh 5 - 5-70
67
RAMP DRAMP - Ramp variable value 9 17 5-74
116
- DRAD 9
Degree → Radian
- 6 5-95
154
RAND DRAND

Random number 7 13 5-131
R
260
RMOV -
9
32-bit Æ 16-bit Conversion 6 - 5-142
02
SRET - - Subroutine Return 1 - 5-16
13
SMOV -

Shift move 11 – 5-24
21
SUB DSUB
9
Subtraction 7 9 5-36
34
SFTR –
9
Bit shift right 9 - 5-50
35
SFTL –
9
Bit shift left 9 - 5-51
38
SFWR –
9
Shift register write 7 - 5-55
39
SFRD –
9
Shift register read 7 - 5-56
43
SUM DSUM

Sum of Active bits 5 9 5-61
48
SQR DSQR

Square Root 5 9 5-67
61
SER DSER

Search a data stack 9 17 5-72
69
SORT DSORT - Data sort 11 21 5-76
147
SWAP DSWAP

Byte swap 3 5 5-130
130
- DSIN
9
Sine 5 6 5-108
136
- DSINH
9
Hyperbolic Sine - 6 5-117
202
SCAL -

Proportional value calculation 9 - 5-132
S
203
SCLP DSCLP

Parameter proportional value calculation 7 13 5-134
79
TO DTO
9
Write CR Data into Special Modules 9 13 5-79
96
TMR - - 16-bit Timer 5 - 4-7
132
- DTAN
9
Tangent 5 6 5-112
T
138
- DTANH
9
Hyperbolic Tangent - 6 5-119
07
WDT –
9
Watchdog timer refresh 1 – 5-18
26
WAND DWAND
9
Logical Word AND 7 9 5-41
27
WOR DWOR
9
Logical Word OR 7 9 5-42
28
WXOR DWXOR
9
Logical XOR 7 9 5-43
36
WSFR –
9
Word shift right 9 - 5-52
W
37
WSFL –
9
Word shift left 9 - 5-54
To Next Page
