Delta DVP-PM Series User Manual

2 Hardware Specifications and Wiring
DVP-PM Application Manual
2-16
5. Wiring of Differential Output
 Wiring of DVP-PM differential output with ASDA-A, ASDA-A+ or ASDA-A2 series servo drive
/PLS
PLS
/SIGN
SIGN
FP
RP
Photocoupler
Circuit
FP+
FP-
RP+
RP-
FG0
Photocoupler
Circuit
43
41
36
37
DVP-20PM differential output
Drive
Twis t e d p air
cable
/PLS
PLS
/SIGN
SIGN
FP
RP
Photocoupler
circuit
Y10+
Y10-
Y11+
Y11-
FG0
Photocoupler
circuit
43
41
36
37
Drive
Twisted pair
cable
DVP-10PM differential output
 Wiring of DVP-PM differential output with ASDA-B series servo drive
/PLS
PLS
/SIGN
SIGN
FP
RP
FP+
FP-
RP+
RP-
FG0
21
22
19
20
Photocoupler
circuit
Photocoupler
circuit
DVP-20PM differential output
Drive
Twisted pair
cable
/PLS
PLS
/SIGN
SIGN
FP
RP
Y10+
Y10-
Y11+
Y11-
FG0
21
22
19
20
Photocoupler
circuit
Photocoupler
circuit
Drive
Twisted pair
cable
DVP-10PM differential output
