Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-2
X External inputs
X0 ~ X377, octal number system, 256 points
(corresponding to physical input points)
Y External outputs
Y0 ~ Y377, octal number system, 256 points
(corresponding to physical output points)
Total 512 points
M0 ~ M499, 500 points (*2)
General
M3000 ~ M4095, 1,096 points (*3)
Latched M500 ~ M999, 500 points (*3)
M
Auxiliary
relay
Special M1000 ~ M2999, 2,000 points (some are latched)
Total 4,096
points. Can be
driven
(ON/OFF) in
program.
T Timer 10ms T0 ~ T255, 256 points (*2)
Total 256
points. The
associated
contact = ON
when timer
reaches preset
value.
C0 ~ C99, 100 points (*2) C0 ~ C99, 100 points (*2)
16-bit
count up
C100 ~ C199, 100 points (*3) C100 ~ C199, 100 points (*3)
C208 ~ C219, 12 points (*2) C208 ~ C219, 12 points (*2)
32-bit
count
up/down
C220 ~ C255, 36 points (*3) C220 ~ C255, 36 points (*3)
C Counter
32-bit
high
speed
C200, C204, 2 points (*2)
C200, C204, C208, C212, C216,
C220, 6 points
Total 250
points. The
associated
contact = ON
when counter
reaches preset
value
General S0 ~ S499, 500 points (*2)
Relay (bit)
S Step point
Latched S500 ~ S1023, 524 points (*3)
Total 1,024
points. Can be
driven
(ON/OFF) in
program.
T
Current value
T0 ~ T255, 16-bit timer. 256 words
The associated
contact = ON
when timer
reaches preset
value.
C0 ~ C199, 16-bit counter, 200 words
C
Current value
C200 ~ C255, 32-bit counter, 56 words
The associated
contact = ON
when counter
reaches preset
value.
General D0 ~ D199, 200 words (*2)
D200 ~ D999, 800 words (*3)
Latched
D3000 ~ D9999, 7,000 words (*3)
Special D1000 ~ D2999, 2,000 words (some are latched)
Register (word)
D
Data
register
Index V0 ~ V7 (16-bit), Z0 ~ Z7, 16 words (32-bit) (*1)
Total 10,000
words. General
storage for
word data. V/Z
can be used for
indirect
designation.
Pointer
P
For CJ, CJN, CALL,
JMP instructions
P0 ~ P255, 256 points
Position
pointer of CJ,
CJN, CALL
and JMP
K-32,768 ~ K32,767 (16-bit operation)
Cons
tant
K Decimal
K-2,147,483,648 ~ K2,147,483,647 (32-bit operation)
