Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-19
Special
M
Function 10M
20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
M1120*
Retain the communication setting of COM2 (RS-485).
Modifying D1120 will be invalid when M1120 is set.
○○○
OFF OFF - R/W
NO
OFF 3-36
M1121 For COM2(RS-485), data transmission ready
○○○
OFF ON - R
NO
OFF -
M1122 For COM2(RS-485), sending request
○○○
OFF OFF - R/W
NO
OFF -
M1123 For COM2(RS-485), data receiving completed
○○○
OFF OFF - R/W
NO
OFF -
M1124 For COM2(RS-485), data receiving ready
○○○
OFF OFF - R
NO
OFF -
M1125 For COM2(RS-485), communication ready status reset
○○○
OFF OFF - R/W
NO
OFF -
M1127 For COM2(RS-485), data sending / receiving completed.
○○○
OFF OFF - R/W
NO
OFF -
M1128
For COM2(RS-485), Transmitting/Receiving status
Indication
○○○
OFF OFF - R
NO
OFF -
M1129 For COM2(RS-485), receiving time out
○○○
OFF OFF - R/W
NO
OFF -
M1136* For COM3(RS-485), retain communication setting
○○○
OFF - - R
NO
OFF 3-36
M1138*
For COM1 (RS-232), retain communication setting.
Modifying D1036 will be invalid when M1138 is set.
○○○
OFF - - R/W
NO
OFF 3-36
M1139*
For COM1(RS-232), ASCII/RTU mode selection when in
Slave mode (OFF: ASCII; ON: RTU)
○○○
OFF - - R/W
NO
OFF 3-36
M1140
For COM2 (RS-485), MODRD / MODWR data receiving
error
○○○
OFF OFF - R
NO
OFF -
M1141
For COM2 (RS-485), MODRD / MODWR parameter
error
○○○
OFF OFF - R
NO
OFF -
M1143*
For COM2(RS-485), ASCII/RTU mode selection when in
Slave mode (OFF: ASCII; ON: RTU)
For COM2(RS-485), ASCII/RTU mode selection when in
Master mode (used together with MODRD/MODWR
instructions OFF: ASCII; ON: RTU)
○○○
OFF - - R/W
NO
OFF 3-36
M1161 8/16 bit mode (ON = 8 bit mode)
○○○
OFF - - R/W
NO
OFF -
M1162
Switching between decimal integer and binary floating
point for SCLP instruction
ON: binary floating point; OFF: decimal integer
○○○
OFF - - R/W
NO
OFF
-
M1168
Designating work mode of SMOV
○ ○ ○
OFF - - R/W NO OFF
M1200* C200 counting mode
○○○
OFF - - R/W
NO
OFF 3-40
M1201 C200 counting mode
○
○○
OFF - - R/W
NO
OFF -
M1203 C200 reset signal
○○○
OFF - - R/W
NO
OFF -
M1204* C204 counting mode
○○○
OFF - - R/W
NO
OFF 3-40
M1205 C204 counting mode
○○○
OFF - - R/W
NO
OFF -
M1207 C204 reset signal
○○○
OFF - - R/W
NO
OFF -
M1208* C208 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF 3-40
M1209 C209 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF -
M1210 C210 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF -
M1211 C211 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF -
M1212* C212 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF 3-40
M1213 C213 counting mode (ON: count down)
○○○
OFF - - R/W
NO
OFF -
