Chapter 3 Fea
tured Functions
The file’s format is correct.
The switch has a path to the TFTP
server
.
Certificate Down
load
Description
Factory Default
TFTP serv
er IP
S
pecify a TFTP server IP
address.
0.0.0.0
Remote File Name
S
pecify a certificate file name which can be downloaded.
None
Certificate
Information
