Delta MS300 User Manual

MS300/MH300 PROFINET Communication Card CMM-PN02
CMM-PN02 Operation Manual
9
3 Installation and Wiring
This section introduces how CMM-PN02 connects to MS300/MH300 and to network.
3.1 Mounting Position of Communication Cards
 MS300 Mounting Position of Communication Card
Frame A–D Frame E and F
(Option card mounting box)
Fig. 3-1
Fig. 3-2
 MH300 Mounting Position of Communication Card
Frame A–D (Option card mounting box)
Frame E and F
(Option card mounting box)
Fig. 3-3
Fig. 3-4

Delta MS300 Specifications

General

Series	MS300
Cooling	Fan cooling
IP Rating	IP20
Input Voltage	3-phase 380 ~ 480VAC
Output Current	Varies by model
Overload Capacity	150% of rated current for 60 seconds
Braking Unit	Built-in or optional
Control Method	V/F control, Sensorless Vector Control
Speed Control Range	1:100 (SVC)
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication Interface	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Dimensions	Varies by model
Weight	Varies by model
