MS300/MH300 PROFINET Communication Card CMM-PN02
CMM-PN02 Operation Manual
18
5 PROFINET Communication Profile
This section describes the general setting model and the way to set the parameters of the
motor drives by the host computer through CMM-PN02, refer to the following sections for the
actual operations. This section is divided into the following items:
1. Profinet comm. card info. (Identification & Maintenance functions (I&M))
2. MS300/MH300 real-time data access method
3. Motor drive handling during disconnection in synchronous mode
4. MS300/MH300 parameter reading and writing in non-real-time mode
5.1 Profinet comm. card info. (Identification & Maintenance functions (I&M))
Profinet provides Identification and Maintenance function (I&M) which supports machinery
commissioning, parameter tuning and repairing. CMM-PN02 supports the I&M0 function
which can be accessed using a read request from the I&M record.
The following table shows the data structure when I&M0 record is returned:
Content
Size
Description
Header
10 bytes
-
Vendor ID
2 bytes
PROFINET Vendor ID of Delta, which is 0x03FB.
Order ID
20 bytes
Order number
Serial number
16 bytes
Serial number
Hardware revision
2 bytes
Hardware revision
Software revision
4 bytes
Revision of the software
Revision counter
2 bytes
Number of revisions
Profile ID
2 bytes
0x00
Profile specific type
2 bytes
No profile specific type (0x0000)
I&M version
2 bytes
Version 1.1 (0x0101)
Supported I&M functions
2 bytes
I&M0 is supported (0x0001).

Delta MS300 Specifications

General

Series	MS300
Cooling	Fan cooling
IP Rating	IP20
Input Voltage	3-phase 380 ~ 480VAC
Output Current	Varies by model
Overload Capacity	150% of rated current for 60 seconds
Braking Unit	Built-in or optional
Control Method	V/F control, Sensorless Vector Control
Speed Control Range	1:100 (SVC)
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication Interface	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Dimensions	Varies by model
Weight	Varies by model
