Delta MS300 User Manual

MS300/MH300 PROFINET Communication Card CMM-PN02
CMM-PN02 Operation Manual
17
4 MH300/MS300 Drive Settings
When you operate MS300/MH300 through CMM-PN02, you should set the
communication card as the source of MS300/MH300 controls and settings. You need to
use the keypad to configure the following parameter addresses to the corresponding
values:
NOTE: To make PLC or the host controller to identify CMM-PN02, it is necessary to load the product
description file of CMM-PN02 (GSDML). You can download it directly from Delta’s official website.
Keypad
Parameter No.
Settings/
Displayed Value
Description of Function
Pr.00-20 8 Set communication card as the source of frequency command.
Pr.00-21 5 Set communication card as the source of control.
Pr.09-30 1 Decoding method is either 60xx or 20xx.
Pr.09-60 12
Communication card identification:
When CMM-PN02 communication card is connected, the value of
this parameter displays “12”.

Delta MS300 Specifications

General

Series	MS300
Cooling	Fan cooling
IP Rating	IP20
Input Voltage	3-phase 380 ~ 480VAC
Output Current	Varies by model
Overload Capacity	150% of rated current for 60 seconds
Braking Unit	Built-in or optional
Control Method	V/F control, Sensorless Vector Control
Speed Control Range	1:100 (SVC)
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication Interface	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH, non-condensing
Dimensions	Varies by model
Weight	Varies by model
