MS300/MH300 PROFINET Communication Card CMM-PN02
CMM-PN02 Operation Manual
1 Introduction
1.1 Introduction to PROFINET IO Communication
PROFINET IO is a fieldbus, a family of industrial computer network protocols, and serves
as a communication between programmable logic controllers (PLC) and distributed field
equipment for EtherNet. This protocol recognizes three classes of devices, IO
Controllers, IO Supervisors and IO Devices, and uses three different communication
channels to exchange data: Standard UDP/IP & TCP/IP Channel, Real-Time (RT)
Channel, and Isochronous Real-Time (IRT) Channel. Standard UDP/IP & TCP/IP
Channel is used to parameterize and configure device and asynchronous operation; RT
Channel is used for synchronous data transmission and warning; IRT Channel is
applied to motion control.
1.2 Features
CMM-PN02 connects MS300/MH300 drive to PROFINET to exchange data with the host
controller easily. This simple network solution saves cost and time for connection and
installation of factory automation. Moreover, its components are compatible with
suppliers’.
By installing CMM-PN02 in MS300/M300 through the main PROFINET device, you can:
1. Control the drive through PROFINET
2. Modify the drive’s parameters through PROFINET
3. Monitor the drive’s status through PROFINET
1.3 Network Functions and Specifications
Item Specifications
Interface RJ45
Number of ports 2 ports
IEEE 802.3
Cable Category 5e shielding 100 M
10/100 Mbps auto-negotiate
PROFINET
Item Specifications
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
-10–50°C (temperature), 90% (humidity)
-25–70°C (temperature), 95% (humidity)
resistance
International standards
IEC 61800-5-1, IEC 60068-2-6/IEC 61800-5-1, IEC 60068-2-27
