Appendix A Optional Accessories
A-17
Wiring Length
Encoder Wiring - Diameter mm² (AWG)
Core Size Number of Cores Wire Standard Standard Wire Length
0.13（AWG26）
10 (4 pairs) UL2464 3 m (9.84 feet)
NOTE
1） For wiring the encoder, please use the shielded twisted-pair cable so as to reduce the interference due to noise.
2
） The shield net must be firmly connected with the SHIELD terminal
.
3
） During wiring, please follow the corresponding provisions for cable wiring so as to avoid hazards and accidents.
Connector Specifications
Title Part No. Manufacturer
PLUG 3M 10120-3000PE 3M
SHELL 3M 10320-52A0-008 3M
