Delta VFD110VL43A-J User Manual

1-14
Frame No. E
W1
W D
H1
H2
S2
H
D1
S1
D2
S3
Unit: mm [inch]
Frame No. W W1 H H1 H2 D D1: D2: S1 S2 S3
E1
370.0
[14.57]
335.0
[13.19]
-
589.0
[23.19]
560.0
[22.05]
260.0
[10.24]
132.5
[5.22]
18.0
[0.71]
13.0
[0.51]
13.0
[0.51]
18.0
[0.71]
E2
370.0
[14.57]
335.0
[13.19]
595.0
[23.43]
589.0
[23.19]
560.0
[22.05]
260.0
[10.24]
132.5
[5.22]
18.0
[0.71]
13.0
[0.51]
13.0
[0.51]
18.0
[0.71]
NOTE
Frame No. E1: VFD300VL43A-J, VFD370VL43A-J, VFD450VL43A-J,
Frame No. E2: VFD300VL23A-J, VFD370VL23A-J, VFD550VL43A-J, VFD750VL43A-J,
