Page #59 background image
4-6
01 Motor Parameters a the parameter can be set during
operation
Parameter
code
Function of the parameter Settings
Default
value
VF
FOCPG
FOCPM
01-00 Control mode
0: VF
1: Reserved
2: Reserved
3: FOCPG
4: Reserved
5: FOCPM
6: Reserved
5
a
01-01
Source of operation
command
0: Operation by using the digital keypad
1: Operation by using the external terminals. The Stop button
on the keypad is disabled.
2: Communication using RS-485. The Stop button on the
keypad is disabled
1
01-02
Motor’s maximum operation
frequency
50.00~600.00Hz
60.00/
50.00
01-03 Motor’s rated frequency 0.00~600.00Hz
60.00/
50.00
01-04 Motor’s rated voltage
230V Series: 0.1V~255.0V
460V Series: 0.1V~510.0V
220.0
440.0
a
01-05 Acceleration time setting 0.00~600.00 seconds 0.00
a
01-06 Deceleration time setting 0.00~600.00 seconds 0.00
01-07 Motor Parameter Auto Tuning 0: No function 0
1: Rolling test for induction motor(IM) (Rs, Rr, Lm, Lx, no-load
current)
2: Static test for induction motor(IM)
3: Reserved
4: Auto measure the angle between magnetic pole and PG
origin
5: Rolling test for PM motor
01-08
Rated current of the induction
motor (A)
40~120% of the drive’s rated current #.##
a
01-09
Rated power of the induction
motor
0~655.35kW #.##
a
01-10
Rated speed of the induction
motor
0~65535rpm
1710 (60Hz 4-pole); 1410 (50Hz 4-pole)
1710
01-11
Number of poles of the
induction motor
2~20 4
