4-16
3 Output current (A) 2.5 times of the rated current of the Hybrid servo
drive is used as 100%
4 Output voltage 2 times of the rated current of the Hybrid servo drive
is used as 100%
5 DC BUS voltage 450V (900V) =100%
6 Power factor -1.000~1.000=100%
7 Power Rated power of the drive =100%
8 Output torque Rated torque =100%
9 PO (0~10V=0~100%)
10 PI (0~10V=0~100%)
11 AUI (-10~10V=0~100%)
12~20 Reserved
Display the speed (rpm) defined by the user
Control mode VF FOCPG FOCPM
Factory default: 0
Settings 0~39999 rpm
Set the maximum speed of the motor corresponding to the 100% flow.
a
Maximum value for the pressure command
Control mode VF FOCPG FOCPM
Factory default: 250
Settings 0~250Bar
The 0~10V for the pressure command on the controller is mapped to 0~the value of this
parameter.
a
Maximum pressure feedback value
Control mode VF FOCPG FOCPM
Factory default: 250
Settings 0~400Bar
The 0~10V for the pressure sensor is mapped to 0~the value of this parameter.
Pressure control mode
Control mode VF FOCPG FOCPM
Factory default: 0
Settings 0: Speed control
1: Pressure control
This parameter determines the control mode of the Hybrid servo drive. It is recommended to use
the speed control at the initial start up. After the motor, pump, pressure sensor, and the entire
system are checked without any error, switch to the pressure control mode to enter the process
control.
Speed bandwidth
Control mode FOCPG FOCPM
Factory default: 20
Settings 0~40Hz
Set the speed response. The larger value indicates the faster response.
a
Pressure feedback filtering time PO
