4-26
Settings 0.0~6553.5mH
Rated current of the synchronous motor
Control mode FOCPM
Factory default: 0.00
Settings 0~655.35 Amps
The user can set the rated current shown on the synchronous motor’s nameplate.
Rated power of the synchronous motor
Control mode FOCPM
Factory default: 0.00
Settings 0.00 – 655.35kW
This Parameter sets the rated power of the synchronous motor.
Rated speed of the synchronous motor
Control mode FOCPM
Factory default: 0
Settings 0~65535
This parameter sets the rated speed of the synchronous motor. It is necessary to refer to the
specifications shown on the motor’s nameplate.
Number of poles of the synchronous motor
Control mode FOCPM
Factory default: 6
Settings 2~20
This parameter sets the number of the synchronous motor’s number of poles (odd number is not
allowed).
Inertia of the synchronous motor’s rotor
Control mode FOCPM
Factory default: 0.0
Settings 0.0~6553.5 *10
-4
kg.m2
Stator’s phase resistance (Rs) oth the synchronous motor
Control mode FOCPM
Factory default: 0
Settings 0~65.535Ω
Enter the phase resistance of the synchronous motor.
stator’s phase inductance(Ld) of the synchronous motor
stator’s phase inductance(Lq) of the synchronous motor
Control mode FOCPM
Factory default: 0.00
Settings 0.0~655.35mH
Enter the synchronous motor’s phase inductance. For surface type magnets (SPM), Ld = Lq; for
built-in magnets (IPM), Ld ≠ Lq.
Back EMF of the synchronous motor
Control mode FOCPM
Factory default: 0
Settings 0~65535 V/krpm
Enter the back EMF of the synchronous motor.
