03 Digital/Analog Input/Output Parameters a the parameter can be set
during operation
Multi-function input command 3 (MI3)
Multi-function input command 4 (MI4)
Multi-function input command 5 (MI5)
Control mode VF FOCPG FOCPM
Factory default: 0
Settings 0: No function
44: Injection signal input
45: Confluence/Diversion signal input
46: Reserved
47: Multi-level pressure PI command 1
48: Multi-level pressure PI command 2
When the value of this parameter is set as 44, the pressure feedback is lower than the pressure
stable region (please refer to the description of Parameter 00-26) so the flow control will be
performed.
When it enters the pressure stable region, the pressure control will be performed.
If the setting value is 45, the confluence (OFF)/diversion (ON) function will be performed. For
detailed operation, please refer to Chapter 2 for wiring and Chapter 3 for tuning.
Please refer to the description Parameters 00-36 if the setting value is 47 and 48,
a
Digital input response time
Control mode VF FOCPG FOCPM
Factory default: 0.005
Settings 0.001~30.000 sec
This parameter is used to delay and confirm the signal on the digital input terminal.
a
Digital input operation direction
Control mode VF FOCPG FOCPM
Factory default: 0
Settings 0~65535
This parameter defines the activation level of the input signal.
Bit 0 for the SON terminal, bit 2 for the EMG terminal, bit 3 for the RES terminal, bits 4~6
correspond to MI3~MI5, respectively.
a
Multi-function output 1 (Relay 1)
Control mode VF FOCPG FOCPM
Factory default: 11
a
Multi-function Output 2 (MOI)
Control mode VF FOCPG FOCPM
Factory default: 0
a
Multi-function Output 3 (MO2)
Control mode VF FOCPG FOCPM
Factory default: 0
Settings 0: No function
1: Operation indication
9: Hybrid servo drive is ready
11: Error indication
44: Displacement switch signal
45: Motor fan control signal
To Next Page
