13
ENGLISH
Example: When the distance is set to 3.6 m for the center
speaker
6
Set the distance between the
center speaker and listening
position.
The distance changes in units
of 0.1 meters (1 foot) each time
the button is pressed. Select
the value closest to the
measured distance.
If “Yes” is selected for “Default”, the settings are automatically reset to
the default values.
Please note that the difference of distance for every speaker should be 6.0
m (20 ft) or less. If you set an invalid distance, a CAUTION notice, such as
screen right will appear. In this case, please relocate the blinking speaker(s)
so that its distance is no larger than the value shown in highlighted line.
7
Enter the setting.
The System Setup Menu reappears.
The AVC-A1SR automatically sets the optimum surround delay time for the listening
room.
• Use this setting to adjust so that the playback level between the different channels is equal.
• From the listening position, listen to the test tones produced from the speakers to adjust the level.
• The level can also be adjusted directly from the remote control unit. (For details, see page 25.)
• When using both surround speakers A and B, their playback levels can be adjusted separately.
Setting the channel level
1
At the System Setup Menu select “Channel Level”.
2
Switch to the Channel Level screen.
3
Select “Test Tone Mode”.
Example: When the “Auto” mode is
selected
4
Select the mode.
Select “Auto” or “Manual”.
• Auto:
Adjust the level while listening to the test tones produced
automatically from the different speakers.
• Manual:
Select the speaker from which you want to produce the
test tone to adjust the level.
5
Select “Surr. Sp.”, then select the surround speaker(s) from which you
want to produce the test tone (A, B or A+B).
• Surr. Sp.: A
Adjusts the balance of the playback level between the channels when
using surround speaker A.
6
Select “Test Tone Start”.
Use the CURSOR buttons to adjust all the speakers to the same volume.
The volume can be adjusted between –12 dB and +12 dB in units of 1 dB.
Example: When the volume
is set to –11.5 dB
while the test tone
is being produced
from the
subwoofer
1spkr
2spkrs
When the surround back speaker setting is set to “1spkr” for “Speaker
Configuration”, this is set to “SB”.
7
Select “Ye s”.
8
a. If the “Auto” mode is selected:
Test tones are automatically emitted from the different
speakers.
The test tones are emitted from the different speakers in
the following order, at 4-second intervals the
first time and second time around, 2-second
intervals the third time around and on:
Flashing
Example: When the volume is
set to –11.5 dB while
the subwoofer is
selected
b. When the “Manual” mode is selected
Move jog stick “ENTER” back and forth to select the
speaker for which you want to output test tones, then
move jog stick “ENTER” left and right to adjust so that the
volume of the test tones from the various
speakers is the same.
Flashing
9
After the above settings are completed, press the ENTER button again.
The “Channel Level” screen reappears.
Press jog stick “ENTER” again to return to the System Setup Menu screen.
• Surr. Sp.: B
Adjusts the balance of the playback level between the channels when using surround speaker B.
• Surr. Sp.: A+B
Adjusts the balance of the playback level between the channels when using surround speakers A and
B at the same time.
The “Surr. Sp.” can only be selected when both surround speakers A and B have been selected at the
“Speaker Configuration” (when both A and B have been set to “Large” or “Small”).
To Next Page
