Denon AVC-A1SR

42
ENGLISH
16
SPECIFICATIONS
2 Audio section
• Power amplifier
Rated output: Front:
170 W + 170 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
220 W + 220 W (6 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Center:
170 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
220 W (6 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Surround:
170 W + 170 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
220 W + 220 W (6 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Surround Back/Multi:
170 W + 170 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
220 W + 220 W (6 Ω/ohms, 1 kHz with 0.7% T.H.D.)
Dynamic power: 190 W x 2 ch (8 Ω/ohms)
310 W x 2 ch (4 Ω/ohms)
390 W x 2 ch (2 Ω/ohms)
Output terminals: Front/Center/Surround Back: 6 ~ 16 Ω/ohms
Surround: A or B 6 ~ 16 Ω/ohms
A + B 8 ~ 16 Ω/ohms
• Analog
Input sensitivity / input impedance: 200 mV / 47 kΩ/kohms
Frequency response: 10 Hz ~ 100 kHz: +0, –3 dB (DIRECT mode)
S/N: 105 dB (DIRECT mode)
Distortion: 0.005% (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output: 1.2 V
• Digital
D/A output: Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.003% (1 kHz, at 0 dB)
S/N ratio — 115 dB
Dynamic range — 112 dB
Digital input: Format — Digital audio interface
• Phono equalizer
(PHONO input — REC OUT)
Input sensitivity: 2.5 mV
RIAA deviation: ±1 dB (20 Hz to 20 kHz)
S/N: 74 dB (A weighting, with 5 mV input)
Rated output / Maximum output: 150 mV / 8 V
Distortion factor: 0.03% (1 kHz, 3 V)
2 Video section
• Standard video jacks
Input / output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz — +0, –3 dB
• S-video jacks
Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.286 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz — +0, –3 dB
• Color component video terminal
Input / output level and impedance: Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B/CB (blue) signal — 0.7 Vp-p, 75 Ω/ohms
P
R
/CR (red) signal — 0.7Vp-p, 75 Ω/ohms
Frequency response: DC ~ 100 MHz — +0, –3 dB
2 General
Power supply: AC 230 V, 50 Hz
Power consumption: 720 W
Maximum external dimensions: 434 (W) x 216 (H) x 486 (D) mm
Mass: 29.0 kg
2 Remote control unit (RC-871)
Batteries: LR6/AA Type (four batteries)
External dimensions: 96 (W) x 38 (H) x 168.5 (D) mm
Mass: 242 g (not including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
VIDEO INPUT
