Denon AVR-1312 User Manual

40
Adjusting the sound field effects
Tone
around items indicate the settings made upon purchase.
Adjust the tonal quality of the sound.
1
Press TONE.
[ ][ENTER] Enter Return
Tone
Tone Control OFF
2
Use o p to select “ON”.
ON Allow tone adjustment (bass, treble).
OFF
Playback without tone adjustment.
NOTE
The tone cannot be adjusted in the direct mode.
3
Press ui to select an item to be set, and use o p to select a setting value.
Bass Adjust low frequency range (bass).
•–6dB – +6dB (0dB)
Treble Adjust high frequency range (treble).
•–6dB – +6dB (0dB)
“Bass” or “Treble” can be set when “Tone Control” is set to “ON”.
NIGHT MODE
around items indicate the settings made upon purchase.
Optimized setting for late-night listening.
Press NIGHT to select your desired mode.
D.Comp:OFF
OFF Not set.
Low Set the adjusted value to “Low”.
Mid
Set the adjusted value to “Middle”.
High Set the adjusted value to “High”.
When a Dolby TrueHD signal is output, “DRC” is displayed on the TV screen.
The setting mode is also changed as shown below.
OFF
Not set.
Low
Set the adjusted value to “Low”.
Mid
Set the adjusted value to “Middle”.
High
Set the adjusted value to “High”.
Auto
Automatic dynamic range compression on/off control according to the source.
•If you do not press any button for approximately 5 seconds, the menu screen light turns off.
Basic version
Advanced version
Information
Advanced version
BD

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
