Denon AVR-1508 Service Manual

104
AVR-1708/1508/688/588/488 AVC-1508AVR-1708 E2 model
CN302A nsp CN,WIRE 5P L000450050010S
CN303A nsp CN,WIRE 8P L000450080010S
CN304 nsp CN,WIRE 3P L000500030050S
CN305 nsp CN,WIRE 10P L000700100030S
CN541 CN,WIRE 3P L000251030080S
CP101 nsp CN.WAFER 14P L102526701400S
CP103 CN.WAFER 07P L101220070010S
CP105 nsp CN.WAFER 4P ANGLE L102526800400S
CP301B nsp CN.FPC 35P L131103500010S
CP302 nsp CN.WAFER 3P ANGLE L102526803010S
CP304 nsp CN.WAFER 3P L101220030000S
CP305 CN.WAFER 10P L101220100010S
JACK301 00D 963 0367 802 JACK,D3.5 EARPHONE G401PJ354H40YS
JACK304 00D 963 0146 403 TER,RCA 3PIN G606308HG110YS
JACK501,502 00D 963 0146 607 TER,BOARD SCREW 8P G614801A0200YS
JACK503 00D 963 0158 608 TER,BOARD SCREW 2P G611201A0200YS
JK302 00D 963 0294 708 JACK,D6.5 PHONE G402PJ612AG0YS
L302 nsp COIL INDUCTOR 10UH D330100700520S
L303 nsp COIL INDUCTOR 100UH D330101001020S
RLY541 00D 963 0366 201 RELAY G5PA-28-MC 24V 5A 1??2?? G680240502030S
RLY543-546 00D 963 0366 201 RELAY G5PA-28-MC 24V 5A 1??2?? G680240502030S
RMC301 00D 963 0217 808 MODULE,REMOCON NJL34H380A E940343800010S
! SW301 00D 963 0145 802 SW,PUSH SDDL-005-S(C-UL) G000122006060S
SW301A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW301C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW302B 00D 963 0095 305 SW,TACT SKHV10920A G180040500010S
SW302C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW303B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW303C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW305B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW307B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW307C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW308B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW308C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW309A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW310 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
