Denon AVR-1508 Service Manual

300
AVR-1708/1508/688/588/488 AVC-1508
16 00D 963 0364 308 KNOB SELECT
AVC1508JP
5087211518020S 1 *
17 00D 963 0364 401 BUTTON 4KEY
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5097213341000S 1 *
17 00D 963 0139 407 BUTTON 4KEY
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5097212341000S 1 *
17 00D 963 0364 504 BUTTON 4KEY
AVR1708SRE2/AVR1508SRE2
5097213341100S 1 *
17 00D 963 0364 607 BUTTON 4KEY
AVR1708SPEUT
5097213341110S 1 *
18 00D 963 0364 700 BUTTON 3KEY
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5097213331000S 2 *
18 00D 963 0139 106 BUTTON 3KEY
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5097212331000S 2 *
18 00D 963 0364 803 BUTTON 3KEY
AVR1708SRE2/AVR1508SRE2
5097213331100S 2 *
18 00D 963 0364 906 BUTTON 3KEY
AVR1708SPEUT
5097213331110S 2 *
19 00D 963 0365 002 BUTTON WIN 3KEY
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5097213371000S 2 *
19 00D 963 0365 105 BUTTON WIN 3KEY
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5090213391000S 2 *
19 00D 963 0365 208 BUTTON WIN 3KEY
AVR1708SRE2/AVR1508SRE2
5097213371100S 2 *
19 00D 963 0365 301 BUTTON WIN 3KEY
AVR1708SPEUT/AVC1508JP
5097213371110S 2 *
20 00D 963 0365 404 BUTTON WIN 6KEY
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5097213361000S 1 *
20 00D 963 0365 507 BUTTON WIN 6KEY
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5090213381000S 1 *
20 00D 963 0365 600 BUTTON WIN 6KEY
AVR1708SRE2/AVR1508SRE2
5097213361100S 1 *
20 00D 963 0365 703 BUTTON WIN 6KEY
AVR1708SPEUT
5097213361110S 1 *
27 nsp BRACKET HEATSINK L 4010213146000S 1 *
28 nsp HEAT SINK MAIN
except for AVR488E3
2120211138000S 1 *
28 nsp HEAT SINK MAIN
AVR488E3
2120211148000S 1 *
29 nsp BRACKET HEATSINK R 4010213136000S 1 *
31 nsp POSISTOR P43T7D330BW16 F320161001020S 1
32 nsp BRACKET PCB 4010210186000S 2
40 00D 963 0214 607 CUSHION FOOT 4050211295000S 4
41 00D 963 0137 904 FOOT 4007210261000S 4
42 nsp CHASSIS MAIN 3200212146000S 1 *
43 nsp SUPPORTER PCB 4070001601010S 3
45 nsp BRACKET TRANS 4010210466002S 1
! 46 00D 963 0367 905 POWER TRANS MAIN
AVR1708E3/AVR688BKE3
8200960660240S 1
! 46 00D 963 0368 001 POWER TRANS MAIN
AVR1708E2
8200960660250S 1
! 46 00D 963 0368 108 POWER TRANS MAIN
AVR1508E3/AVR1508EUT/
AVR588E3
8200960660260S 1
! 46 00D 963 0368 205 POWER TRANS MAIN
AVR1508E2
8200960660270S 1
! 46 00D 963 0368 302 POWER TRANS MAIN
AVR1508JP
8200960660290S 1
! 46 00D 963 0368 409 POWER TRANS MAIN
AVR488E3
8200960660280S 1
70 00D 963 0360 402 CHASSIS BACK
AVR1708E3
3207212156500S 1 *
70 00D 963 0360 505 CHASSIS BACK
AVR688E3
3207212156510S 1 *
70 00D 963 0360 608 CHASSIS BACK
AVR1708E2
3207212156600S 1 *
70 00D 963 0360 701 CHASSIS BACK
AVR1508E3
3207212156800S 1 *
70 00D 963 0360 804 CHASSIS BACK
AVR588E3
3207212156A00S 1 *
70 00D 963 0360 907 CHASSIS BACK
AVR1508E2
3207212156610S 1 *
70 00D 963 0361 003 CHASSIS BACK
AVR1508EUT
3207212156700S 1 *
70 00D 963 0361 106 CHASSIS BACK
AVC1508JP
3207212156400S 1 *
70 00D 963 0361 209 CHASSIS BACK
AVR488E3
3207212156900S 1 *
71 00D 963 0145 608 TUNER PACK
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
E903014000020S 1 *
71 00D 963 0145 705 TUNER PACK
AVR1708E2/AVR1508E2/
AVR1508EUT
E903014100030S 1 *
72 00D 960 0192 403 STOPPER CORD AC
except for AVC1508JP
4380210002000S 1
! 73 00D 963 0292 205 AC CORD
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
L068125100020S 1
! 73 00D 963 0292 302 AC CORD
AVR1508EUT
L068125110000S 1
Ref. No. Part No. Part Name Remarks Q'ty New
