Denon AVR-1508 - Front P.w.b. Unit Assy

206
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 EUT model
FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC301 00D 963 0074 504 IC BU2090F-E2 J044209000010S
IC302 00D 262 3758 009 LC87F6D64A-QFP-E J127876160010S
! IC303 00D 960 0195 808 IC ICP-N15 J120001500030S
IC304 00D 963 0024 004 IC NJM2068M J121206800020S
Q301-303 00D 963 0120 704 TR KRA102S J520010200210S
Q304 00D 963 0121 606 TR KRC107S J522107S00210S
Q305 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q306 00D 963 0120 801 TR KRC102S J522010200210S
Q307-309 00D 963 0120 704 TR KRA102S J520010200210S
Q310,311 00D 963 0120 801 TR KRC102S J522010200210S
Q312 00D 960 0133 103 TR KSA916Y J5000916Y0050S
Q542-546 00D 963 0121 208 TR KRC107M J6020107M0010S
D301,302 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D303 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D304 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D305-311 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D312 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D313-316 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D542 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D543-545 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D546 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
ZD302-305 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD307,308 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD309 00D 960 0095 801 D,ZENER MTZJ6.8B K06006R844520S
ZD310,311 00D 963 0046 202 D,ZENER MTZJ18B K06018R044520S
LED302-309 00D 960 0197 204 LED PI5-RD/HL50RDRF4T K500052015010S
LED310 00D 963 0366 108 LED BL-BEG204-L 5PI K500052004010S
FL301 00D 963 0257 305 DISPLAY,FLT HNA-16SM13T K530161300020S
RESISTORS GROUP
R372 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R378,379 00D 960 9009 270 R,METAL FILM 470-J,2W C060047166520S
RP1-38 00D 963 0353 005 R,CHIP THICK 56K-J,1/16W C20005636M160S
RG1-16 00D 963 0353 005 R,CHIP THICK 56K-J,1/16W C20005636M160S
CAPACITORS GROUP
C301,302 nsp C,CERAMIC 100PF-J/50V D010101167160S
C303 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C304 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C305 nsp C,CERAMIC 100PF-J/50V D010101167160S
C306 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C307 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C308 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C311 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C312 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
