Denon AVR-1508 Service Manual

201
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 EUT model
Q541 00D 963 0121 208 TR KRC107M J6020107M0010S
D101C 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101FL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101FR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101SL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101SR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102C 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102FL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102FR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D105C 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105FL 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105FR 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105SL 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105SR 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D106,107 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D114,115 00D 960 0197 107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
D139 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D140,141 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D142 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D143-152 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D153 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D154-157 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D541 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
ZD101 00D 963 0058 601 D,ZENER MTZJ12B K06012R044520S
ZD101C 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD102C 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102FL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102FR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102SL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102SR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD105 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
RESISTORS GROUP
R101 00D 963 0337 801 R,METAL FILM 100-J,2W C060010166520S
R103 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R104 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R104C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105 00D 963 0232 906 R,METAL FILM 47K-F,1/4W C060047343530S
R105C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
