Denon AVR-1508 Service Manual

297
AVR-1708/1508/688/588/488 AVC-1508
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊ P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement
parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
AVR1708E3 : U.S.A. & Canada model AVR1708E2 : Europe model AVR688E3 : U.S.A. & Canada model
AVR1508E3 : U.S.A. & Canada model AVR1508E2 : Europe model AVR1508EUT : Taiwan R.O.C. model
AVR588E3 : U.S.A. & Canada model AVR 488E3 : U.S.A. & Canada model
AVC1508JP : Japan model
Black : Black model
Premium Silver
: Premium Silver model
Silver
: Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
57A nsp POWER P.W.B. ASSY
AVR1708E3
7025HK0705013 1 *
57A nsp POWER P.W.B. ASSY
AVR688E3
7025HK0705023 1 *
57A nsp POWER P.W.B. ASSY
AVR1708E2
7025HK0705033 1 *
57A nsp POWER P.W.B. ASSY
AVR1508E3
7025HK0704023 1 *
57A nsp POWER P.W.B. ASSY
AVR588E3
7025HK0704033 1 *
57A nsp POWER P.W.B. ASSY
AVR1508E2
7025HK0704043 1 *
57A nsp POWER P.W.B. ASSY
AVR1508EUT
7025HK0704053 1 *
57A nsp POWER P.W.B. ASSY
AVC1508JP
7025HK0704063 1 *
57A nsp POWER P.W.B. ASSY
AVR488E3
7025HK0704013 1 *
26 GUIDE L
30 GUIDE R
56 POWER SUPPLY ASSY
57 POWER ASSY
11A nsp FRONT P.W.B. ASSY
AVR1708E3
7025HK0705011 1 *
11A nsp FRONT P.W.B. ASSY
AVR688E3
7025HK0705021 1 *
11A nsp FRONT P.W.B. ASSY
AVR1708E2
7025HK0705031 1 *
11A nsp FRONT P.W.B. ASSY
AVR1508E3
7025HK0704021 1 *
11A nsp FRONT P.W.B. ASSY
AVR588E3
7025HK0704031 1 *
11A nsp FRONT P.W.B. ASSY
AVR1508E2
7025HK0704041 1 *
11A nsp FRONT P.W.B. ASSY
AVR1508EUT
7025HK0704051 1 *
11A nsp FRONT P.W.B. ASSY
AVC1508JP
7025HK0704061 1 *
11A nsp FRONT P.W.B. ASSY
AVR488E3
7025HK0704011 1 *
9 POWER SW ASSY
10 FUNCTION ASSY
11 FRONT ASSY
14 HEAD PHONE ASSY
21 V- AUX ASSY
22 MIC ASSY
except for AVR1508E3/
AVR1508EUT/AVR588E3/AVR488E3
55 SPEAKER ASSY
50A nsp MAIN P.W.B ASSY
AVR1708E3
7025HK0705010 1 *
50A nsp MAIN P.W.B ASSY
AVR688E3
7025HK0705020 1 *
50A nsp MAIN P.W.B ASSY
AVR1708E2
7025HK0705030 1 *
50A nsp MAIN P.W.B ASSY
AVR1508E3
7025HK0704020 1 *
50A nsp MAIN P.W.B ASSY
AVR588E3
7025HK0704030 1 *
50A nsp MAIN P.W.B ASSY
AVR1508E2
7025HK0704040 1 *
50A nsp MAIN P.W.B ASSY
AVR1508EUT
7025HK0704050 1 *
50A nsp MAIN P.W.B ASSY
AVC1508JP
7025HK0704060 1 *
50A nsp MAIN P.W.B ASSY
AVR488E3
7025HK0704010 1 *
50 MAIN ASSY
