Denon AVR-1508 Service Manual

298
AVR-1708/1508/688/588/488 AVC-1508
51A nsp CPU P.W.B. ASSY
AVR1708E3
7025HK0705015 1 *
51A nsp CPU P.W.B. ASSY
AVR688E3
7025HK0705025 1 *
51A nsp CPU P.W.B. ASSY
AVR1708E2
7025HK0705035 1 *
51A nsp CPU P.W.B. ASSY
AVR1508E3
7025HK0704025 1 *
51A nsp CPU P.W.B. ASSY
AVR588E3
7025HK0704035 1 *
51A nsp CPU P.W.B. ASSY
AVR1508E2
7025HK0704045 1 *
51A nsp CPU P.W.B. ASSY
AVR1508EUT
7025HK0704055 1 *
51A nsp CPU P.W.B. ASSY
AVC1508JP
7025HK0704065 1 *
51A nsp CPU P.W.B. ASSY
AVR488E3
7025HK0704015 1 *
51 CPU ASSY
52A nsp INPUT P.W.B. ASSY
AVR1708E3
7025HK0705012 1 *
52A nsp INPUT P.W.B. ASSY
AVR688E3
7025HK0705022 1 *
52A nsp INPUT P.W.B. ASSY
AVR1708E2
7025HK0705032 1 *
52A nsp INPUT P.W.B. ASSY
AVR1508E3
7025HK0704022 1 *
52A nsp INPUT P.W.B. ASSY
AVR588E3
7025HK0704032 1 *
52A nsp INPUT P.W.B. ASSY
AVR1508E2
7025HK0704042 1 *
52A nsp INPUT P.W.B. ASSY
AVR1508EUT
7025HK0704052 1 *
52A nsp INPUT P.W.B. ASSY
AVC1508JP
7025HK0704062 1 *
52A nsp INPUT P.W.B. ASSY
AVR488E3
7025HK0704012 1 *
52 INPUT ASSY
53A nsp VIDEO P.W.B. ASSY
AVR1708E3
7025HK0705017 1 *
53A nsp VIDEO P.W.B. ASSY
AVR688E3
7025HK0705027 1 *
53A nsp VIDEO P.W.B. ASSY
AVR1708E2
7025HK0705037 1 *
53A nsp VIDEO P.W.B. ASSY
AVR1508E3
7025HK0704028 1 *
53A nsp VIDEO P.W.B. ASSY
AVR588E3
7025HK0704038 1 *
53A nsp VIDEO P.W.B. ASSY
AVR1508E2
7025HK0704048 1 *
53A nsp VIDEO P.W.B. ASSY
AVR1508EUT
7025HK0704058 1 *
53A nsp VIDEO P.W.B. ASSY
AVR488E3
7025HK0704018 1 *
53 VIDEO ASSY
54A 00D 963 0368 700 HDMI P.W.B. ASSY
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
7025HK0705016 1 *
54 HDMI ASSY
54B 00D 963 0368 807 HDMI P.W.B. ASSY
AVR1708E2/AVR1508E2/
AVR1508EUT/AVC1508JP
7025HK0705036 1 *
54 HDMI ASSY
33A nsp 2CH P.W.B. ASSY
AVR1708E3
7025HK0705014 1 *
33A nsp 2CH P.W.B. ASSY
AVR688E3
7025HK0705024 1 *
33A nsp 2CH P.W.B. ASSY
AVR1708E2
7025HK0705034 1 *
33A nsp 2CH P.W.B. ASSY
AVR1508E3
7025HK0704024 1 *
33A nsp 2CH P.W.B. ASSY
AVR588E3
7025HK0704034 1 *
33A nsp 2CH P.W.B. ASSY
AVR1508E2
7025HK0704044 1 *
33A nsp 2CH P.W.B. ASSY
AVR1508EUT
7025HK0704054 1 *
33A nsp 2CH P.W.B. ASSY
AVC1508JP
7025HK0704064 1 *
33 2CH ASSY
33B nsp 2CH POWER P.W.B ASSY
AVR488E3
7025HK070401A 1 *
33 SUB ASSY
include
58A nsp D-VIDEO P.W.B.
AVC1508JP
7025HK0704069 1 *
58 VIDEO ASSY
59 D-VIDEO1 ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
