Denon AVR-1508 Service Manual

299
AVR-1708/1508/688/588/488 AVC-1508
60 D-VIDEO2 ASSY
1 00D 963 0358 509 WINDOW
AVR1708E3
5077212382000S 1 *
1 00D 963 0358 602 WINDOW
AVR688E3
5077211922200S 1 *
1 00D 963 0358 705 WINDOW
AVR1708E2/1508E2
5077212382010S 1 *
1 00D 963 0358 808 WINDOW
AVR1508E3
5077212382030S 1 *
1 00D 963 0358 901 WINDOW
AVR588E3
5077211922220S 1 *
1 00D 963 0359 100 WINDOW
AVR1508EUT
5077212382040S 1 *
1 00D 963 0359 203 WINDOW
AVC1508JP
5077212382050S 1 *
1 00D 963 0359 306 WINDOW
AVR488E3
5077211922210S 1 *
2 00D 963 0361 704 KNOB FUNCTION
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5087211461000S 1 *
2 00D 963 0138 301 KNOB FUNCTION
AVR688E3/AVR588E3/
AVR488E3
5087210961000S 1 *
2 00D 963 0361 807 KNOB FUNCTION
AVR1708SRE2/AVR1508SRE2
5087211461100S 1 *
2 00D 963 0361 900 KNOB FUNCTION
AVR1508SPEUT
5087211461110S 1 *
2 00D 963 0362 006 KNOB FUNCTION
AVC1508JP
5087211508020S 1 *
3 00D 963 0362 109 BADGE
Black
5630210028300S 1 *
3 00D 963 0051 527 BADGE
Silver
5630210028200S 1 *
3 00D 963 0362 202 BADGE
Premium Silver
5630210028400S 1 *
4 00D 963 0359 409 PANEL FRONT
AVR1708BKE3
3067213241000S 1 *
4 00D 963 0359 502 PANEL FRONT
AVR688BKE3
3067213271010S 1 *
4 00D 963 0359 605 PANEL FRONT
AVR1708BKE2
3067213241400S 1 *
4 00D 963 0359 708 PANEL FRONT
AVR1708SRE2
3067213241100S 1 *
4 00D 963 0359 801 PANEL FRONT
AVR1508BKE3
3067213241200S 1 *
4 00D 963 0359 904 PANEL FRONT
AVR588BKE3
3067213271110S 1 *
4 00D 963 0360 000 PANEL FRONT
AVR1508SRE2
3067213241110S 1 *
4 00D 963 0360 103 PANEL FRONT
AVR1508SPEUT
3067213241300S 1 *
4 00D 963 0360 206 PANEL FRONT
AVC1508JP
3067213258030S 1 *
4 00D 963 0360 309 PANEL FRONT
AVR488E3
3067213271100S 1 *
5 00D 963 0137 807 LENS STANDBY 3710210503000S 1
6 00D 963 0184 009 BUTTON POWER
Black
5097212358000SZ 1
6 00D 963 0139 805 BUTTON POWER
Silver
5097212358100SZ 1
6 00D 963 0230 005 BUTTON POWER
Premium Silver
5097212358300SZ 1
7 00D 963 0184 106 BUTTON STANDBY
Black
5097212368000SZ 1
7 00D 963 0140 108 BUTTON STANDBY
Silver
5097212368010SZ 1
7 00D 963 0221 904 BUTTON STANDBY
Premium Silver
5097212368030SZ 1
8 00D 963 0361 601 FRAME FRONT
AVC1508JP
3217211521200S 1 *
8 00D 963 0362 305 BUTTON 2KEY
Black
5097213351000S 1 *
8 00D 963 0362 408 BUTTON 2KEY
Silver
5097213351100S 1 *
8 00D 963 0362 501 BUTTON 2KEY
Premium Silver(except for
AVC1508JP)
5097213351110S 1 *
12 00D 963 0190 307 COVER RCA
Black
4317211701000S 1
12 00D 963 0190 307 COVER RCA
Silver
4317211701100S 1
13 00D 960 0191 417 LENS LED
except for AVC1508JP
3710210043001S 2
13 00D 960 0229 304 LENS LED
AVC1508JP
37102100230015 2
15 00D 963 0362 604 KNOB VOLUME
AVR1708BKE3/AVR1708BKE2/
AVR1508BKE3
5087211471000S 1 *
15 00D 963 0138 806 KNOB VOLUME
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5087210981000S 1 *
15 00D 963 0362 707 KNOB VOLUME
AVR1708SRE2/AVR1508SRE2
5087211471100S 1 *
15 00D 963 0362 800 KNOB VOLUME
AVR1708SPEUT
5087211471110S 1 *
15 00D 963 0362 903 KNOB VOLUME
AVC1508JP
5087211498020S 1 *
16 00D 963 0363 009 KNOB SELECT
AVR1708BKE3AVR1708/BKE2/
AVR1508BKE3
5087211481000S 1 *
16 00D 963 0344 302 KNOB SELECT
AVR688BKE3/AVR588BKE3/
AVR488BKE3
5087211281000S 1 *
16 00D 963 0364 102 KNOB SELECT
AVR1708SRE2/AVR1508SRE2
5087211481100S 1 *
16 00D 963 0364 205 KNOB SELECT
AVR1708SPEUT
5087211481110S 1 *
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
