Denon AVR-1508 Service Manual

293
AVR-1708/1508/688/588/488 AVC-1508AVC-1508 JP model
D-VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1308,1309 00D 963 0068 002 IC BU4052BCF-E2 J040405200060S
IC1310 00D 960 0175 200 IC BA7625 J171762500000S
IC1311,1312 00D 963 0083 304 IC BA7626 J171762600000S
IC1313 00D 960 0239 104 IC KIA7806API J126780600130S
IC1314-1316 00D 963 0148 401 IC LA7956 J171795600010S
Q1318-1320 00D 960 0005 105 TR KTA1266Y J5001266Y0050S
Q1321,1322 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q1323-1326 00D 963 0121 208 TR KRC107M J6020107M0010S
Q1327-1330 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q1331-1334 00D 963 0121 208 TR KRC107M J6020107M0010S
D1306 00D 963 0355 401 D,SWITCHING CHIP KDS4148U K005041480030S
D1307-1310 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
CAPACITORS GROUP
C1353-1364 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1365 00 D96 3900 596 C,ELECT 4700UF-M/6.3V D040472081000S
C1366,1367 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1368-1370 00D 963 0311 607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1371-1376 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1377 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1378 00D 963 0311 607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1379 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1381 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1383 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1384 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1385 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1386-1394 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C1395-1400 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060S
C1402 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1403 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1404,1405 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1406,1407 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1408,1409 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
OTHERS PARTS GROUP
CN1303 nsp CN.WAFER 5P L101220050010S
CN1305 nsp CN.WAFER 18P L101100041810S
CN1306 nsp CN.WAFER 19P L101100041910S
CP1304 nsp CN.WAFER 9P L101100030910S
CP1305 nsp CN.WAFER 18P L101100031810S
CP1306 nsp CN.WAFER 19P L101100031910S
JACK1305 00D 963 0218 108 TER,RCA 3PIN G60630401000YS
JACK1306 00D 963 0218 001 TER,RCA 2PIN G60122001000YS
JACK1307-1310 00D 204 6670 010 D-CONNECTOR L170001200010S
nsp HEAT SINK 2120044338010S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH
B020030081B10S

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
