Denon AVR-1508 Service Manual

109
AVR-1708/1508/688/588/488 AVC-1508AVR-1708 E2 model
CP501 nsp CN.WAFER 2CKT,YEL L108353280290S
CP503 nsp CN.WAFER 2CKT,RED L108353280280S
CP504 nsp CN.WAFER ST2P L108202000220S
CP505 nsp CN.WAFER 7P L101100040710S
CP506 nsp CN.WAFER 12P L101100041210S
CP512 nsp CN.WAFER 4P ANGLE L102526800400S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 CN.WAFER 13P L101220130000S
! F501 00D 963 0237 600 FUSE T2.5A /250V N751222501110S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
! F503 00D 963 0104 704 FUSE T3.15A /250V N751223151110S
F503A nsp HOLDER,FUSE CLIP G645000050010S
F503B nsp HOLDER,FUSE CLIP G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
RLY501 00D 963 0218 205 RELAY HL3-1A-9SH DC9V 1A G680090102020S
! SUB501 00D 963 0382 801 SUB TRANS 8200280150410S
nsp HEAT SINK 2120043538030S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH
B020030081B10S
nsp SHIELD PLATE GND 3070045526010S
! 00D 960 0143 203 SOCKET,POWER RECEPTA G435040110000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
