Denon AVR-1508 Service Manual

260
AVR-1708/1508/688/588/488 AVC-1508AVR-488 E3 model
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 nsp CN.WAFER 13P L101220130000S
! F501 00D 963 0236 106 FUSE T8A /250V N751228001110S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
! F503 00D 963 0236 106 FUSE T8A /250V N751228001110S
F503A nsp HOLDER,FUSE CLIP G645000050010S
F503B nsp HOLDER,FUSE CLIP G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
RLY501 00D 963 0218 205 RELAY HL3-1A-9SH DC9V 1A G680090102020S
! SUB501 00D 963 0382 704 SUB TRANS 8200280150400S
nsp HEAT SINK 2120043538030S
nsp HEAT SINK 2120044298010S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH
B020030081B10S
nsp SHIELD PLATE GND 3070045526010S
! 00D 203 3976 002 SOCKET,POWER RECEPTA G435204004010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
