Denon AVR-1508 Service Manual

189
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 E2 model
2CH-AMP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401D 00D 960 0159 501 IC KIA7805API J126780500110S
IC401H 00D 963 0366 500 IC KIA1117PI33 J126111733050S
IC402D 00D 963 0366 500 IC KIA1117PI33 J126111733050S
IC402X 00D 963 0366 603 IC KIA1117PI50 J126111750050S
IC403 00D 963 0334 503 IC PQ20RX11 J126201100010S
IC403D 00D 963 0366 706 IC KIA1117PI00 J126111700050S
Q401SBL 00D 963 0044 204 TR 2SD2390-Y J5032390Y0000S
Q401SBR 00D 963 0044 204 TR 2SD2390-Y J5032390Y0000S
Q401X 00D 963 0120 801 TR KRC102S J522010200210S
Q402D 00D 963 0120 801 TR KRC102S J522010200210S
Q402SBL 00D 963 0044 107 TR 2SB1560-Y J5011560Y0000S
Q402SBR 00D 963 0044 107 TR 2SB1560-Y J5011560Y0000S
Q402X 00D 963 0120 801 TR KRC102S J522010200210S
Q403SBL 00D 963 0280 107 TR 2SC3964 J502396400000S
Q403SBR 00D 963 0280 107 TR 2SC3964 J502396400000S
Q404SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q404SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q406SBL 00D 960 0196 205 TR KSA992F J5000992F0050S
Q406SBR 00D 960 0196 205 TR KSA992F J5000992F0050S
Q407SBL 00D 960 0196 205 TR KSA992F J5000992F0050S
Q407SBR 00D 960 0196 205 TR KSA992F J5000992F0050S
Q408SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q408SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q409 00D 963 0327 808 TR KTA1281Y J5001281Y0010S
D401D 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D401H 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D401SBL 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D401SBR 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D401X 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D402D 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402H 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402SBL 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D402SBR 00D 963 0341 004 D,SWITCHING KDS4148U K005041480030S
D402X 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D403 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
ZD401SBL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ S K06603R34P400S
ZD401SBR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ S K06603R34P400S
ZD402SBL 00D 963 0367 008 D,ZENER 0.2W 3.0V UDZ S K06603R04P400S
ZD402SBR 00D 963 0367 008 D,ZENER 0.2W 3.0V UDZ S K06603R04P400S
RESISTORS GROUP
R401D 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401H 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401X 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402D 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402H 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402X 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R410SBL 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R410SBR 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
