37
AVR-1708/1508/688/588/488 AVC-1508
69 P23 HPD1 O HDMI_IN2 HPD Control Pin
70 P22 H/P DET I HP Jack Insert Detection(Det ="H")
71 P21 FUNCTION UP I FUNCTION SELECTOR KNOB(Rotary Encoder)Rotational Detection
72 P20 FUNCTION DOWN I FUNCTION SELECTOR KNOB(Rotary Encoder)Rotational Detection
73 P17/INT5 RMC I Remote Control Unit Signal Reception
74 P16/INT4 MIC IN I MIC Insert Detection(Det ="H")
75 P15/INT3 POWER Key I POWER KEY Detection
76 P14/D12 POWER RELAY O MAIN TRANS RELAY Control Pin
77 P13/D11 RED LED O POWER/STANDBY LED Control Pin
78 P12/D10 VOL DATA O FUNCTION/VOLUME(IC700 : R2A15215) Control Pin
79 P11/D9 VOL CLK O FUNCTION/VOLUME(IC700 : R2A15215) Control Pin
80 P10/D8
1328 SDIN/
MIC OVERLOAD
I CODEC(IC808 : ADAU1328) Control Pin
81 P07/D7 4094(MUTE)_STB O IC111 : BU4094(EXPANDER) Control Pin
82 P06/D6 4094(RLY)_STB O IC110 : BU4094(EXPANDER) Control Pin
83 P05/D5 4094(XM)_STB O IC12 : BU4094(EXPANDER) Control Pin
84 P04/D4 89057/1328 SCLK O DIR(IC807 : LC89057)&CODEC(IC808 : ADAU1328) Control Pin
85 P03/D3 89057/1328 SDOUT O DIR(IC807 : LC89057)&CODEC(IC808 : ADAU1328) Control Pin
86 P02/D2 COMP DET I COMPONENTSignal Detection (AVR-1708/688 Only)
87 P01/D1 CVBS DET I CONPOSIT Signal Detection (AVR-1708/688 Only)
88 P00/D0 S-VIDEO DET I S VIDEO Signal Detection (AVR-1708/688 Only)
89 P107/AN7 4094_OE O IC12&110&111 : BU4094(EXPANDER) Control Pin
90 P106/AN6 KEY1 I Key-1 Detection(A/D)
91 P105/AN5 KEY2 I Key-2 Detection(A/D)
92 P104/AN4 KEY3 I Key-3 Detection(A/D)
93 P103/AN3 1328 RESET O CODEC(IC808 : ADAU1328) Control Pin
94 P102/AN2 SET OPTION I Area Setup
95 P101 4094_CLK O IC12&110&111 : BU4094(EXPANDER) Control Pin
96 AVSS AVSS - GND
97 P100 4094_DATA O IC12&110&111 : BU4094(EXPANDER) Control Pin
98 VREF VREF - AD Reference Level(+5V)
99 AVCC AVCC - AD +5V
100 P97/SIN4 INH O Identifying Signal Control (AVC-1508 Only)
PIN NO. PIN NAME I/O FUNCTION
To Next Page
