Denon AVR-1508 Service Manual

301
AVR-1708/1508/688/588/488 AVC-1508
! 73 00D 963 0292 409 AC CORD
AVR1708E2/AVR1508E2
L068250250040S 1
74 00D 963 0158 404 AC INLET
AVC1508JP
G430040560020S 1
75 nsp LABEL ORIGIN
AVR1508EUT
5507003020021S 1
80 00D 963 0361 302 CABINET TOP
Black
3000210936000S 1 *
80 00D 963 0361 405 CABINET TOP
Silver/Premium Silver
3000210936100S 1 *
80 00D 963 0361 508 CABINET TOP
AVC1508JP
3000210926100S 1 *
81 nsp COVER SAFETY
E2, EUT model
4310212122010S 1 *
82 nsp COVER HOLDER
E2, EUT model
4310213701000S 1 *
83 nsp CUSHION SIDE 4050211095000S 3 *
84 nsp CUSHION PCB 4050211105000S 1 *
85 nsp SUPPORTER BUTTON LOCK 4070000020000S 1 *
★ 86
nsp LABEL RATING FUSE CAUTION
for only E3 model
1
87 nsp LABEL(TRANS) 1
88 00D 342 0043 000 FERRITE CLAMP102010N 1
★ 91
00D 963 0365 806 CABLE,FLAT CARD 1.25MM N712151344810S 1 *
★ 92
00D 963 0365 909 CABLE,FLAT CARD 1.25MM
except for AVC1508JP
N712351534810S 1 *
T1 00D 963 0044 107 TR 2SB1560-Y J5011560Y0000S 5 *
T2 00D 963 0280 107 TR 2SC3964 J502396400000S 5 *
T3 00D 963 0044 204 TR 2SD2390-Y J5032390Y0000S 5
Screws
A nsp SCREW(3X8 B-TYPE ZNY/BH)
AVR1708E3/AVR1708E2/
AVR1508E2/AVR688E3
B020030081B10S 66
A nsp SCREW(3X8 B-TYPE ZNY/BH)
AVR1508E3/AVR1508EUT/
AVR588E3/AVR488E3
B020030081B10S 63
A nsp SCREW(3X8 B-TYPE ZNY/BH)
AVC1508JP
B020030081B10S 73
B nsp SCREW(3X8 BK WASHER PI12)
Black
1500001456020S 5
B nsp SCREW(3X8 BK WASHER NI12)
Silver / Premium Silver
1500001456030S 5
C nsp SCREW(3X15 B-TYPE ZNY/BH) B020030151B10S 2
D nsp SCREW(3X10 B-TYPE(DOT) BK/BH)
AVR1708E3/AVR688E3/
AVC1508JP
B020030103B11S 36
D nsp SCREW(3X10 B-TYPE(DOT) BK/BH)
AVR1708E2/AVR1508E3/
AVR1508E2/AVR1508EUT/
AVR588E3
B020030103B11S 35
D nsp SCREW(3X10 B-TYPE(DOT) BK/BH)
AVR488E3
B020030103B11S 34
Ensp
SCREW(3X14 P+S-WASHER ZNY/HH)
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3
B018230141H11S 25
Ensp
SCREW(3X14 P+S-WASHER ZNY/HH)
AVR1708E2/AVR1508E2/
AVR1508EUT/AVC1508JP
B018230141H11S 24
Ensp
SCREW(3X14 P+S-WASHER ZNY/HH) AVR488E3
B018230141H11S 19
F nsp SCREW(3X17 B-TYPE ZNY/BH) B020030171B10S 3
G 00D 963 0048 307 SCREW(4X8 B-TYPE(DOT) BK/BH)
Black
1500040083B10S 6
G 00D 963 9004 012 SCREW(4X8 B-TYPE(DOT) NI/BH)
Silver / Premium Silver
1500040084B10S 6
Hnsp
SCREW(4X10 P+S-WASHER ZNY/BH)
B028940101B10S 4
I nsp SCREW(3X8 ZnY WASHER PI12) 1500001456010S 3
J nsp SCREW(4X6 S-TYPE ZNY/BH) B020740061B10S 6
L nsp SCREW(3X10 B-TYPE BK/FH)
AVC1508JP
B020030103F10S 2
P nsp SCREW(3X6 S-TYPE BK/BH) B020030063B10S 2
Q nsp SCREW(3X8 S-TYPE BK/BH) B020930083B10S 5
R nsp SCREW(3X10 TAPPING BK/PH)
AVC1508JP
B010230103P10S 8
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
