Denon AVR-1508 Service Manual

107
AVR-1708/1508/688/588/488 AVC-1508AVR-1708 E2 model
C781 00D 960 9008 640 C,FILM 0.022UF-J/100V D02022306C060S
C782 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C783 nsp C,FILM 0.15UF-K/63V D020154078060S
C784-790 00D 963 0293 806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C791-793 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C794 00D 963 0293 806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C795-799 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
OTHERS PARTS GROUP
CLAMP501 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN514 nsp CN,WIRE 13P L000181130010S
CN702 nsp CN.HOUSING 15P L120912150010S
CN703 nsp CN.WAFER 8P L101100030810S
CN704 nsp CN.WAFER 19P L101100031910S
CN706 nsp CN,WIRE 8P L000121080010S
CP704 nsp CN.WAFER 15P L101220150000S
JACK701-703 00D 963 0132 103 TER,RCA 4PIN G602405B0400YS
JACK704,705 00D 963 0132 307 TER,RCA 6PIN G603603B05000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
