Denon AVR-1508 Service Manual

19
AVR-1708/1508/688/588/488 AVC-1508
2.4. VCR MONITOR OUT(S) Output NG
VCR/DVR MONITOR OUT(S) Output NG.
※ When checking operation, select
DVD for the function.
I n p u t
CVBS
Input
S
Input
COMPONENT
No output VCR : F No output
2.4. VCRMONITOROUT(S) 出力 NG
VCR/DVRMONITOROUT(S) 出力 NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
入力
CVBS
入力
S
入力
COMPONENT
出力されません VCR:F 出力されません

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
