Denon AVR-1508 Service Manual

208
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 EUT model
RMC301 00D 963 0217 808 MODULE,REMOCON NJL34H380A E940343800010S
! SW301 00D 963 0145 802 SW,PUSH SDDL-005-S(C-UL) G000122006060S
SW301A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW301C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW302B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW303B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW303C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW305B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW307B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW307C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW308B 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW308C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW309A 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
SW310 00D 963 0045 708 SW,TACT SKHV10920A G180000270010S
VEC203 00D 963 0300 401 SW,ENCODER EC11B20C2 G121112020000S
VEC301 00D 963 0095 208 SW,ENCODER EC16B24SA G121162400040S
VEC303 00D 963 0095 208 SW,ENCODER EC16B24SA G121162400040S
nsp HOLDER FLT 4320200026000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
