Denon AVR-1508 Service Manual

227
AVR-1708/1508/688/588/488 AVC-1508AVR-588 E3 model
C111FL 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C111FR 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C111SL 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C111SR 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C112 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C112C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C113C 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C113FL 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C113FR 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C113SL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C113SR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C114 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C114C 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114FL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114FR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114SL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114SR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C115 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C115SW 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C117-120 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C141SW1 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C142SW1 nsp C,CERAMIC 100PF-J/50V D010101167160S
C161 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C162,163 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C164 nsp C,CERAMIC 100PF-J/50V D010101167160S
C166,167 nsp C,CERAMIC 100PF-J/50V D010101167160S
C168-172 00D 963 0244 606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C177 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C178,179 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C180,181 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C182 00D 963 0324 005 C,ELECT 100UF-M/100V D04010108C240S
C183 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C190 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
OTHERS PARTS GROUP
BKT101 nsp SHIELD PLATE GND 3070045526010S
CN101 nsp CN,WIRE 14P L000111140010S
CN103 nsp CN,WIRE 7P L000141070020S
CN201 nsp CN,WIRE 4P L000700100020S
CN704 nsp CN,WIRE 15P L000600150030S
CP102 nsp CN.WAFER 4P L102526700400S
CP104 nsp CN.WAFER 3CKT L108353280360S
CP106 nsp CN.WAFER 5P L101100040510S
CP107 nsp CN.WAFER 3P L102526700300S
CP108 nsp CN.WAFER 17P L101100041710S
CP511 nsp CN.WAFER 9P L101220090000S
CP541 nsp CN.WAFER 3P L101220030000S
GND101 nsp TERMINAL EARTH 3790040886000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
