Denon AVR-1508 Service Manual

262
AVR-1708/1508/688/588/488 AVC-1508AVR-488 E3 model
C408D4 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C408X4 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C409D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C410D4 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C411D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C443X4 nsp C,CERAMIC 1000PF-K/50V D011102777160S
OTHERS PARTS GROUP
CN404H4 nsp CN,WIRE 4P L000451040020S
CN405X4 nsp CN,WIRE 5P L000401050030S
CN904D4 nsp CN,WIRE 6P L000201060010S
CP401 nsp CN.WAFER 3P L102526700300S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
