Denon AVR-1508 Service Manual

276
AVR-1708/1508/688/588/488 AVC-1508AVC-1508 JP model
CP511 nsp CN.WAFER 9P L101220090000S
CP541 nsp CN.WAFER 3P L101220030000S
GND101 nsp TERMINAL EARTH 3790040886000S
JACK221 90M -YT 0046 40R TER,RCA 2PIN G601207AE020YS
JACK222 TER,RCA 1PIN G600107A0000YS
L101C 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101FL 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101FR 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101SL 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101SR 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
RLY541 00D 963 0218 506 RELAY BC3-24 24V 2A G680240202040S
TP101-105 nsp CN.WAFER 3P L101530140310S
JP108 00D 963 0223 009 R,CHIP THICK 0-J,1/16W C20000006M160S
JP347 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
JP350 00D 963 0223 009 R,CHIP THICK 0-J,1/16W C20000006M160S
JP351 00D 963 0223 009 R,CHIP THICK 0-J,1/16W C20000006M160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
