Denon AVR-1508 Service Manual

93
AVR-1708/1508/688/588/488 AVC-1508AVR-1708 E3 model
C1011 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1012,1013 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1014,1015 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1016,1017 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1018 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1019,1020 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1021 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1022 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1023-1025 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1026 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1027,1028 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1029,1030 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1032,1033 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1035,1036 00D 963 0294 106 C,ELECT 2.2UF-M/50V (Pb Free) D0402R2087160S
C1037 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1038,1039 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1041 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1042-1044 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1045-1050 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1051,1052 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1053,1054 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1055,1056 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1057,1058 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1059,1060 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
C1061-1069 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1070-1078 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1079-1082 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1083 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1084,1085 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1086 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1087 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1088 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1089 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1090 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1091 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1092 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1093 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1094 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1095-1097 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1098 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1099-1101 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1102 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1103 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1104 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1105 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1106 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1107 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1108,1109 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C1113 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050S
C1114 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1115 00D 963 0130 105 C,FILM 1UF-K/63V D020105078060S
C1116 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1117 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1118 00D 963 0024 907 C,ELECT 1000UF-M/6.3V D040102081060S
C1119,1120 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1121,1122 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
