Denon AVR-1611 Service Manual

101
Pin Pin Name Synbol I/O Type Det
Op
(Int.)
Pu/Pd
(Ext.)
Res
PURE
D
CEC
STBY
P.OFF Function
58 P32 DAC MDI O C - - - Z O/L O/L Z DAC control pin (ASK4358)
59 P31 DAC MC O C - - - Z O/L O/L Z DAC control pin (ASK4358)
60 VCC VCC - - - - - - - - - +3.3V
61 P30 DAC MS O C - - - Z O/L O/L Z DAC control pin (ASK4358)
62 VSS VSS - - - - - - - - - GND
63 P27 DAC RST O C - - - Z O/H O/L Z DAC control pin (ASK4358)
64 P26 DV POWER O C - - - Z O/L
MODE1=O/H
MODE2=O/L
Z "DIGITAL VIDEO power control pin (DV5V,DV3.3V)
65 P25/INT7 NC I - Lv - Pd Z - - Z NC
66 P24/INT6 1TX INT I - Lv - DV3Pu Z - - Z
HDMI OUT1 signal presence detection input
(HDMI TRANS1 ADV7511)
67 P23 SUB TMS O C - - DA3.3Pu Z O/L - Z PLD rewriting control (JTAG)
68 P22 VEXP STB O C - - - Z O/L O/L Z NC
69 P21 VEXP OE O C - - - Z O/L O/L Z NC
70 P20 VEXP CLK O C - - - Z O/L O/L Z NC
71 P17/INT5 ADVINT1 I - E↓&L - - Z - - Z HDMI RECEIVER(ADV7840) INT1 output
72 P16/INT4 ADVINT2 I - E↓&L - - Z - - Z HDMI RECEIVER(ADV7840) INT2 output
73 P15/INT3 ADVINT3 I - E↓&L - - Z - - Z HDMI RECEIVER(ADV7840) INT3 output
74 P14 HPD4 O C - - - Z O/L O/L Z HP DET control pin
75 P13/TXD6 DSP MOSI O C - - DA3VPu Z O/L O/L Z DSP control pin (ADSP-21367-333)
76 P12/RXD6 DSP MISO I - Lv - DA3VPu Z - - Z DSP control pin (ADSP-21367-333)
77 P11/CLK6 DSPICLK O C - - DA3VPu Z O/L O/L Z DSP control pin (ADSP-21367-333)
78 P10 Z1VSIG.DET I - Lv - SCPU3VPu Z - - Z VIDEO IN signal presence detection input signal (input:H)
79 P07 SUB TDI O C - - DA3.3Pu Z O/L O/L Z PLD rewriting control (JTAG)
80 P06 NC I - - - Pd Z - - Z NC
81 P05 NC I - - - Pd Z - - Z NC
82 P04 NC I - - - Pd Z - - Z NC
83 P03 SUB TCK O C - - Pd Z O/L - Z PLD rewriting control (JTAG)
84 P02 NC I - - - Pd Z - - Z NC
85 P01 NC I - - - Pd Z - - Z NC
86 P00 DIR RST1 O C - - - Z O/L O/L O/L DIR control pin (LC89058W-VF4A)
87 P107/(AN7) DSP RST O C - - - Z O/L O/L Z DSP(ADSP-21367-333) reset output pin (Reset : L)
88 P106/(AN6) NC I - - - Pd Z - - Z NC
89 P105/(AN5) DSP ROMRST O C - - - Z O/L O/L Z Memory reset for DSP (Reset : L)
90 P104/(AN4) COMPS DET I - Lv - SCPU3VPu Z - - Z COMPONENT IN signal presence detection input
91 P103/(AN3) DSP FLAG0 I - Lv - Pd Z - - Z DSP control pin ADSP-21367-333
92 P102/(AN2) DSP ICS O C - - DA3VPu Z O/L O/L Z DSP control pin ADSP-21367-333
93 P101/(AN1) NC I - - - Pd Z - - Z NC
94 AVSS AVSS - - - - - - - - - AD GND
95 P100/(AN0) NC I - - - Pd Z - - Z NC
96 VREF VREF - - - - - - - - - AD standard +3.3V
97 AVCC AVCC - - - - - - - - - AD +3.3V
98 P97/(SIN4) NC I - - - Pd Z - - Z NC
99 P96/(SOUT4) NC I - - - Pd Z - - Z NC
100 P95/(CLK4) VEXP DIN O C - - - Z O/L O/L Z NC

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
