Denon AVR-1611 Service Manual

17
1. μcom/DSP Version display mode
1.1. Operation specifi cations
μcom/DSP version display mode:
When started up, the version information is displayed.
Starting up:
With the "DIMMER" and "STATUS" buttons pressed, press the "ON/STANDBY" button to turn the power on.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
1.2. Display Order
Destination information  Main-com version  Main 1st Boot version  Sub-com version 
Sub 1st Boot Loader Version  DSP version  APLD version
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Display order is
q
,
w
,
e
,
r
,
t
.
Condition State State
q
Sub-com NG No response from Sub-com
SUB ERROR 01
w
DIR NG No response from DIR
DIR ERROR 01
e
DSP1 NG
When DSP boot, executing DSP reset makes no change to DSP1 FLAG0
port "H".
DSP ERROR 01
No change to DSP FLAG0 port "H" before issuing DSP command.
DSP ERROR 02
When DSP data read, executing WRITE="L" makes no change to ACK="H".
DSP ERROR 03
When DSP data read, executing REQ="L" makes no change to ACK="L".
DSP ERROR 04
When DSP data write, executing WRITE="H" makes no change to ACK="H".
DSP ERROR 05
When DSP data write, executing REQ="L" makes no change to ACK="L".
DSP ERROR 06
When DSP special code boot, executing DSP reset makes no change to
DSP FLAG0 port "H".
DSP ERROR 11
No change to DSP FLAG0 port "H" before issuing DSP special read
command.
DSP ERROR 12
No change to DSP FLAG0 port "H" before DSP version read.
DSP ERROR 13
r
EEPROM NG Error appeared in EEPROM checksum.(*** is a block address number.)
E2PROM ERR***
t
Both SUB/DSP
/EEPROM OK
(No error display, version display only)

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
